5
PITCHING INSTRUCTIONS
SETTING UP YOUR TENT
1. Assemble the poles (Fig. 1A, 1B and 1C).
DO NOT allow the shockcord to snap the pole sections
together, this can damage the poles.
4. Insert a pole end into the buckle in the corner clip
(Fig. 4A and 4B). NOTE: Pole end snaps into buckle.
2. Spread the tent body on the ground.
3. Locate a plastic corner clip located on the webbing
at the corner ground seams (Fig. 3A).
Figure 1A
Figure 1B
Figure 1C
Figure 3A
5. Flex the pole and inser
t the other end into the corner
clip at the opposite tent corner.
Repeat steps 4 and 5
with the remaining pole.
Figure 4A
Figure 4B
