Getting Started

2.2.4 TCMxxxx-… (remote version)

Fig. 7: Operating Elements TCM

1 = Locking screw for screw type terminals

2 = Cable gland for cable to the TCE

3 = Fluid output, flange / thread as ordered

4 = Screw for protective ground (TCM0325 through 3100 only)

5 = Fluid input, flange / thread as ordered

6 = M6 mounting threads (back side, option, TCM0300 through 3000 only)
