Kemppi MasterTig 235ACDC GM User Manual

MasterTig 235ACDC, 325DC, 335ACDC
Operating manual - EN
MASTERTIG 235ACDC GM
235ACDC GM
(VRD locked on)
Feature Description Value
Range of output (110 V) TIG
3 A / 1 V ... 130 A / 24 V 3 A / 1 V ... 130 A / 24 V
MMA
10 A / 1 V ... 85 A / 35 V 10 A / 1 V ... 85 A / 35 V
Power factor, λ 230 V, MMA 180 A /
27.2 V
0.99 0.99
Efficiency, ƞ 230 V, MMA 120 A /
24.8 V
84 % 84 %
Idle power TIG
20 W 20 W
Operating temperature range
-20...+40 °C -20...+40 °C
Storage temperature range
-20...+60 °C -20...+60 °C
EMC class
A A
Degree of protection
IP23S IP23S
External dimensions LxWxH
544 x 205 x 443 mm 544 x 205 x 443 mm
Weight without accessories
19.1 kg 19.1 kg
Arc-on signal for relay
24 V / 50 mA 24 V / 50 mA
Voltage supply for cooling unit U
cu
220...240 V (cooler not sup-
ported in 110 V)
240 V (cooler not supported in
110 V)
Recommended generator power
(min)
S
gen
8 kVA 8 kVA
Wireless communication type:
- Control panels MTP23X, MTP33X,
MTP35X
(2
- Remote controls HR45, FR45
(2
Transmitter frequency
and power
2.4 GHz Bluetooth, 2400-
2483.5 MHz, 10 dBm
2.4 GHz Bluetooth, 2400-
2483.5 MHz, 10 dBm
Wired communication type
Remote
Analog Analog
CAN BUS
Kemppi Remote-Bus Kemppi Remote-Bus
Arc striking voltage
5...11 kV 5...11 kV
Stick electrode diameters ø mm
1.6...5.0 mm 1.6...5.0 mm
Standards
IEC 60974-1,-3,-10
IEC 61000-3-12
GB 15579.1
IEC 60974-1,-3,-10
IEC 61000-3-12
AS 60974.1-2006
GB 15579.1
2)
NO: These devices are not allowed to be used within a 20 km radius of the centre of Ny-Ålesund at Svalbard, Nor-
way. This restriction applies to any 2-32 GHz transmitter operation.
© Kemppi
60/77 1920900 / 1939

Kemppi MasterTig 235ACDC GM Specifications

General

Brand	Kemppi
Model	MasterTig 235ACDC GM
Category	Welding System
Language	English
