X5 FastMig
Operating manual - EN
2.12 Installing and replacing feed rolls
The installation method described here is the same with both X5 Wire Feeder 200 and X5 Wire Feeder 300. Model-spe-
cific variations in the visual appearance and positioning may occur.
Replace the feed rolls when the material and diameter of the filler wire changes.
Proceed as follows:
1. Open the wire feeder cabinet.
2. Release the pressure handles on the wire feed mechanism.
3. Open the locking arms to release the feed rolls.
© Kemppi
59
1920960 / 2144
