X8 MIG WELDER 2.3 Installation
Changing wire liner (gas-cooled gun)
Caution:
Use the correct wire liner. The tip of the filler wire may damage an incorrect liner.
1.
Lay the welding gun cable straight on a flat surface.
2.
Loosen the neck tightener by rotating it half a turn, and remove the neck.
3.
Remove the guide nut from the tip of the sleeve.
4.
Remove the sleeve and pull out the liner. Make sure the cone and the seal slide out with the liner.
OPERATING MANUAL | EN 63
©
KEMPPI | 2018-09-28
