CONVERSION INSTRUCTIONS
5
Conversion Instructions for 16656
Before starting the conversion, make sure
all control knobs are in the OFF position,
LP tank valve is closed, and tank is
disconnected from regulator and removed
from grill. Next, open all lids and remove
warming racks, cooking grids, and heat
diffusers. (Fig. 1)
Main Burner Conversion
1. Remove the R pins at the back of main
burners to detach burners from bracket.
(Fig. 2)
2. Lift back of main burners while sliding
burners out of firebox, disengaging main
burners from valves. (Fig. 3)
Warming
rack
Heat diffusers
Fig. 1
Grids
Fig. 3
Main burne
