Kenmore 600 Series User Manual

7
PARTS LIST
Key
Description
Qty
Part Number
Key
Description
Qty
Part Number
1
End Cap, Right Side Shelf
1
30800206C
35
Door Hinge
2
30800236
2
Right Side Shelf
1
41500300
36
Swivel Caster
2
30800238
3
Fascia, Right Side Shelf
1
41500301
37
Swivel Caster With Brake
2
30800237
4
Igniter Wire, Side Burner
1
41500213C
38
Battery Box
1
41500054
5
Lid, Side Burner
1
41500302
39
Battery Module
1
41500223
6
Rotate Rod, Side Burner Lid
1
41500205
40
Ignition Module Cover
1
30800246
7
Cooking Grid ,Side Burner
1
41500303
41
Electronic Ignition Module
1
41500214
8
Side Burner
1
41500224
42
Magnet
4
40200094
9
Side Burner Base
1
41500304
43
Right Side Panel
1
30800051C
10
Side Burner Bracket C
1
41500305
44
Cart Support Angle Bar
2
41500316
11
Control Panel
1
41500024
45
Side Panel Slide bar bracket
2
41500317
12
Light Switch Seat
1
41500221
46
Drawer Handles
2
41500318
13
Waterproof Switch
2
41500220
47
Top Magnet Box
1
41500319
14
Ground Wire
1
30800244
48
Door Bracket
1
41500320
15
Pulse Control Line
1
41500215
49
Gas Tank Tray
1
30800112C
16
Gas Valve, Main Burner
4
41500306
50
Drawer Slider Bar
4
30800252C
17
Manifold
1
41500307
51
Drawer Front Panel
2
41500321
18
Gas Hose L220
1
40900228
52
Drawer Assembly
2
41500322
19
Gas Valve, Side Burner
1
41500308
53
Magnet
2
40200094
20
Manifold, Side Burner
1
41500309
54
Middle Cart panel
1
41500323
21
Gas Hose
1
30800217C
55
Middle Cart Panel Retention Bracket
1
41500324
22
Regulator Retention Bracket
1
41500310
56
Left Door
1
41500061C
23
Connector B
1
30800218C
57
Door Handle
1
30800068C
24
Regulator W / Fuel Gauge
1
30800258C
58
Match Holder Assembly
1
41500325
25
Regulator hose hanger clip
1
30800226
59
Left Side Panel
1
41500326
26
LED Light Strip
1
41500222
60
Back Panel
1
41500327
27
Bezel, Control Knob
5
41500311
61
Gas Tank Holder
1
30800253C
28
Control Knob
5
30800219E
62
Transformer
1
41500216
29
Tank Tray Slider Bar
2
30800252C
63
Wire slot C
1
41500053
30
Tank tray bracket
2
41500312
64
Hole Grommet
2
30800245
31
Bottom Magnet Box
1
41500313
65
Lamp control wires
1
41500217
32
Bottom Shelf
1
41500314
66
Main Burner Electrode L370
1
41500209C
33
Magnet
2
40200094
67
Main Burner Electrode L540
1
41500210C
34
Wire Clamp
2
41500315
68
Main Burner Electrode L710
1
41500211C
