PARTS LIST
Key
Description
Qty
Part Number
Key
Description
Qty
Part Number
69
Main Burner Electrode L880
1
41500212C
83
Lid left handle seat
1
30800247C
70
Drip box
1
30800082C
84
Lid right handle seat
1
30800248C
71
Grease Panel
1
30800019C
85
Isolation Spacer Lid handle
2
30800259C
72
Main Burner
4
30800086
86
Cotter Pin
6
110050
73
Fascia, Left Side Shelf
1
30800036
87
Lid
1
41500002C
74
End Cap, Left Side Shelf
1
30800205C
88
Warming Rack
1
41500204
75
Left Side Shelf
1
30800031
89
Cooking Grid
3
41500206C
76
Lid handle
1
41500006C
90
Wire slot B
1
41500015
77
Lid Rubber Bumper, Front
2
30800233
91
Wire slot A
1
41500014
78
Lid Rubber Bumper, Back
2
40800107
92
Lamp
2
41500218
79
Temperature Gauge
1
30800207
93
Light Bulb
2
41500218-1
80
Temp Gauge Bezel
1
30800208
94
Lamp holder
2
41500021
81
Logo
1
30800209
95
Heat Diffuser
4
41500013
82
Rotate Rod, Lid
2
40800108
96
Firebox
1
41500008C
97
Nylon Knot
1
41500900
Not Pictured
Hardware Pack
1
41500330C
Manual
1
41500319E
If you are missing hardware or have
damaged parts after unpacking grill,
call 1-888-287-0735 , M – F 8:00 –5:00
PACIFIC for replacement.
To order replacement parts after using grill,
call 1-888-287-0735 , M – F 8:00 –5:00
PACIFIC.
Language Spoken: English& Spanish
NOTES: Some grill parts shown in the assembly steps may differ slightly in appearance
from those on your particular grill. However, the method of assembly remains the same.
