Kenmore 970-4204 Series Use & Care Guide

10
Door Removal / Reversal Instructions
Handle Style 2
To remove refrigerator metal handle:
1. Loosen the set screw on the rounded part of the
handle.
2. Remove the 2 screws from the top of the handle.
3. Remove rounded part of handle from mounting screw
on face of door.
To attach refrigerator metal handle:
1. Place rounded part of handle onto mounting screw
on face of door and align the 2 holes in top of
handle with the 2 holes in top of door. Handle should
be mounted with set screw facing towards center of
door. Do not tighten the set screw yet.
2. Install the 2 screws into the top of the handle.
3. Tighten the set screw on the rounded part of the
handle until the handle is ush with the door, and
then tighten another ½ turn.
Mounting
To remove freezer handle:
1. Loosen the set screw on the rounded part of the
handle.
2. Remove the 2 screws from the bottom of the handle.
3. Remove rounded part of handle from mounting screw
on face of door.
To attach freezer handle:
1. Place rounded part of handle onto mounting screw
on face of door and align the 2 holes in bottom of
handle with the 2 holes in bottom of door. Handle
should be mounted with set screw facing towards
center of door. Do not tighten the set screw yet.
2. Install the 2 screws into the bottom of the handle.
3. Tighten the set screw on the rounded part of the
handle until the handle is ush with the door, and
then tighten another ½ turn.
Mounting
To reverse refrigerator/freezer handles:
Handles may be easier to reverse while doors are o.
Reverse freezer and refrigerator handles by inverting the
handle removed from the refrigerator door and attaching
to the freezer door. Invert the handle removed from
freezer door and attach to the refrigerator door.
