9
Leveling Instructions
Door Removal
If door must be removed:
1. Unplug the unit or switch the breaker that supplies power to the unit to the o position.
2. Remove the plastic top hinge cover.
3. Hold the door in place while removing the top hinge from the cabinet.
4. Remove the 2-⅜” hex head screws from the top hinge with a wrench or socket.
5. Lift the door upwards and pull up and away from the cabinet until free of the
bottom hinge pin mounted on the front of the cabinet.
6. To replace the door, reverse the above procedures and securely tighten all screws to
prevent hinge slippage.
CAUTION
Doors are heavy. It is recommended to
have two people to remove or replace the
door assembly from the cabinet.
Hinge Cover
Hinge Plate
Hex Head
Screws (2)
