WARNING
To avoid risk of electrical shock that can cause death or severe personal injury,
disconnect unit from power before servicing unless tests require power.
2. Specifications
Item Specification
Model Name RFP74KB* (111.7302****)
S
E
N
S
O
R
Defrost A3J-41A
Freezer A3R-32D
Refrigerator A3J-41A
Ice Maker A3R-35D
RT A3J-41A
H
E
A
T
E
R
Sheath F AS 200W / 115V
Sheath R AS 200W / 120V
R Motor AS(In URT) 10W / 115V
R Motor AS(Behind EVA) NA
R Return Duct AS 7W / 115V
W/Tank AS NA
Hose AS 5.5W / 115V
DV AS 8W / 115V
Dispenser AS NA
I/Flap AS NA
E
L
E
C
T
R
I
C
A
L
P
A
R
T
S
Fuse Temp (Defrost)
AC250V , 10A , 77℃
Freezer-Fan Motor
D4612AAA29 / DC13V / 1850±150 rpm
Refrigerator-Fan Motor
D4612AAA36 / DC13V / 2100±200 rpm
Condenser-Fan Motor
D4612AAA28 / DC13V / 1100±150 rpm
Freezer-Lamp 5-LED
Refrigerator-Lamp 9-LED
Dispenser-Lamp NA
Door Switch(Freezer / Refrigerator) SP201R-7DR/SP101B-201(G)
