PARTS LIST

Indicates safety critical com po nents.

Ref. No.

Parts No. Description

Desti-

nation

: DDX7019

: DNX7100 (North America)

: DDX7029

: DDX7029Y

: DNX7200 (Europe)

: DDX7039 (Australia)

: DDX7039 (Latin America)

: DDX7039 (Other Areas)

Ref. No.

Parts No. Description

Desti-

nation

DDX7019/7029/7029Y/7039

DNX7100/7200

C122,123 CK73GB1H103K CHIP C 0.010UF K

C124 C93-1367-05 CHIP C 10UF K

C128,129 CK73GB1H102K CHIP C 1000PF K

C130

✽

CE32AV0J221M CHIP EL 220UF 6.3WV

C131-133 CK73GB1H103K CHIP C 0.010UF K

C134 C93-1367-05 CHIP C 10UF K

C136,137 CK73GB1H102K CHIP C 1000PF K

C140

✽

CE32AV1A121M CHIP EL 120UF 10WV

C141 CK73GB1H103K CHIP C 0.010UF K

C142 CK73GB1H473K CHIP C 0.047UF K

C143 CK73GB1H102K CHIP C 1000PF K

C145 CC73GCH1H221J CHIP C 220PF J

C146 CK73GB1H102K CHIP C 1000PF K

C147 CK73GB1H103K CHIP C 0.010UF K

C148 CC73GCH1H101J CHIP C 100PF J

C149 CC73GCH1H470J CHIP C 47PF J

C150 CK73GB1H153K CHIP C 0.015UF K

C151 CC73GCH1H470J CHIP C 47PF J

C152 CK73GB1H223K CHIP C 0.022UF K

C153 CK73GB1H102K CHIP C 1000PF K

C155 CC73GCH1H221J CHIP C 220PF J

C156,157 CK73GB1H104K CHIP C 0.10UF K

C158 CK73FB0J106K CHIP C 10UF K

C159 CK73GB1H104K CHIP C 0.10UF K

C160 CK73EB1E225K CHIP C 2.2UF K

C161,162 CK73GB1H104K CHIP C 0.10UF K

C163,164 CK73GB1H103K CHIP C 0.010UF K

C165 C93-1367-05 CHIP C 10UF K

C166,167 CE32BM1E470M CHIP EL 47UF 25WV

C168 CK73GB1H103K CHIP C 0.010UF K

C169,170 CK73GB1H102K CHIP C 1000PF K

C171

✽

CE32AV0J221M CHIP EL 220UF 6.3WV

C172-174 CK73GB1H103K CHIP C 0.010UF K

C175 C93-1367-05 CHIP C 10UF K

C176,177 CE32BM1E470M CHIP EL 47UF 25WV

C178 CK73GB1H104K CHIP C 0.10UF K

C179,180 CK73GB1H102K CHIP C 1000PF K

C181

✽

CE32AV0G331M CHIP EL 330UF 4.0WV

C182 CK73GB1H103K CHIP C 0.010UF K

C183,184 CK73GB1H102K CHIP C 1000PF K

C185 CK73GB1H103K CHIP C 0.010UF K

C186 CK73GB1H104K CHIP C 0.10UF K

C187 CK73GB1H103K CHIP C 0.010UF K

C188-201 CK73GB1H104K CHIP C 0.10UF K

C202 CK73GB1H103K CHIP C 0.010UF K

C203 CK73GB1H104K CHIP C 0.10UF K

C204 CK73FB0J475K CHIP C 4.7UF K

C205 CK73GB1H104K CHIP C 0.10UF K

C206 CC73GCH1H220J CHIP C 22PF J

C207 CC73GCH1H180J CHIP C 18PF J

C208,209 CK73GB1H104K CHIP C 0.10UF K

C210 CK73GB1H103K CHIP C 0.010UF K

C212 CK73FB0J106K CHIP C 10UF K

C213 CK73GB1H221K CHIP C 220PF K

C214 CK73GB1H103K CHIP C 0.010UF K

C215-219 CK73GB1H104K CHIP C 0.10UF K

C260 CK73GB1H102K CHIP C 1000PF K

C301 CK73GB1A105K CHIP C 1.0UF K

C302

✽

CE32AV0J121M CHIP EL 120UF 6.3WV

C303 CK73GB1H104K CHIP C 0.10UF K

C304-309 CK73GB1H103K CHIP C 0.010UF K

C310 CC73GCH1H821J CHIP C 820PF J

C311 CK73GB1A105K CHIP C 1.0UF K

C312 CK73EB1A106K CHIP C 10UF K

C313 CK73GB1A105K CHIP C 1.0UF K

C314 CK73GB1H682K CHIP C 6800PF K

C316,317 CK73GB1H104K CHIP C 0.10UF K

C318 CK73GB1H103K CHIP C 0.010UF K

C319 CC73GCH1H050C CHIP C 5.0PF C

C320 CK73GB1A474K CHIP C 0.47UF K

C321 CK73GB1H103K CHIP C 0.010UF K

C322 CC73GCH1H080D CHIP C 8.0PF D

E1E2M1

C322 CC73GCH1H080D CHIP C 8.0PF D X1E3

C323

✽

CE32AV0J121M CHIP EL 120UF 6.3WV

C324 CK73GB1H104K CHIP C 0.10UF K

C325 C93-1403-05 CHIP C 22UF M

C326 CE32BJ1C101M CHIP EL 100UF 16WV

C327,328 CK73GB1H104K CHIP C 0.10UF K

C329 CK73GB1H102K CHIP C 1000PF K

C330,331 CK73GB1H103K CHIP C 0.010UF K

C332 CC73GCH1H390J CHIP C 39PF J

C333 CK73GB1H103K CHIP C 0.010UF K

C334 CK73EB1A106K CHIP C 10UF K

C335 CK73GB1H103K CHIP C 0.010UF K

C339 CE32BJ1C220M CHIP EL 22UF 16WV

C340-342 CK73FB0J106K CHIP C 10UF K

C343-345 CK73GB1H102K CHIP C 1000PF K

C346 CK73GB1H103K CHIP C 0.010UF K

C347 CC73GCH1H101J CHIP C 100PF J

C359 CK73GB1H104K CHIP C 0.10UF K

C361 CK73GB1H104K CHIP C 0.10UF K

C362 CK73GB1H103K CHIP C 0.010UF K

C363 CK73GB1H104K CHIP C 0.10UF K

C364 CK73GB1H103K CHIP C 0.010UF K

C400-403 CK73GB1A474K CHIP C 0.47UF K

C404 CK73GB1H103K CHIP C 0.010UF K

C405 CE32BJ1C470M CHIP EL 47UF 16WV

C406 CK73GB1H104K CHIP C 0.10UF K

C407 CK73GB1H103K CHIP C 0.010UF K

C408-413 CK73GB1A105K CHIP C 1.0UF K

C414 CK73GB1H103K CHIP C 0.010UF K

C415-420 CK73GB1A105K CHIP C 1.0UF K

C421 CK73GB1H103K CHIP C 0.010UF K

C422-426 CK73GB1A105K CHIP C 1.0UF K

C427 CK73GB1H103K CHIP C 0.010UF K

C429,430 CK73GB1A105K CHIP C 1.0UF K

C431,432 CK73GB1H103K CHIP C 0.010UF K

C433 CK73FB0J106K CHIP C 10UF K

C435 CE32BJ1C220M CHIP EL 22UF 16WV

C436,437 CK73FB0J106K CHIP C 10UF K

VIDEO CONTROL UNIT (X14-985x-xx)
