Kenwood DDX7029 Service Manual

PARTS LIST
Indicates safety critical com po nents.
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
K
: DDX7019
K1
: DNX7100 (North America)
E1
: DDX7029
E2
: DDX7029Y
E3
: DNX7200 (Europe)
X1
: DDX7039 (Australia)
R1
: DDX7039 (Latin America)
M1
: DDX7039 (Other Areas)
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
DDX7019/7029/7029Y/7039
DNX7100/7200
66
R91 RK73GB2A472J CHIP R 4.7K J 1/10W M1X1K1
R92 RK73EB2E152J CHIP R 1.5K J 1/4W E3
R92 RK73EB2E152J CHIP R 1.5K J 1/4W
M1X1K1
R93 RK73GB2A621J CHIP R 620 J 1/10W E3
R93 RK73GB2A621J CHIP R 620 J 1/10W M1X1K1
R94 RK73GB2A242J CHIP R 2.4K J 1/10W E3
R94 RK73GB2A242J CHIP R 2.4K J 1/10W
M1X1K1
R95,96
✽
RK73PB2H2R0J CHIP R 2.0 J 1/2W E3
R95,96
✽
RK73PB2H2R0J CHIP R 2.0 J 1/2W M1X1K1
R97 RK73GB2A124J CHIP R 120K J 1/10W E3
R97 RK73GB2A124J CHIP R 120K J 1/10W
M1X1K1
R98 RK73GB2A103J CHIP R 10K J 1/10W E3
R98 RK73GB2A103J CHIP R 10K J 1/10W
M1X1K1
R99 RK73GB2A473J CHIP R 47K J 1/10W E3
R99 RK73GB2A473J CHIP R 47K J 1/10W
M1X1K1
R102 RK73GB2A472J CHIP R 4.7K J 1/10W
R103-106 RK73GB2A473J CHIP R 47K J 1/10W
R107 RK73GB2A101J CHIP R 100 J 1/10W
R108 RK73GB2A471J CHIP R 470 J 1/10W
R109-112 RK73GB2A101J CHIP R 100 J 1/10W
R113 RK73GB2A473J CHIP R 47K J 1/10W
R114-117 RK73GB2A101J CHIP R 100 J 1/10W
R118 RK73GB2A223J CHIP R 22K J 1/10W
R119-122 RK73GB2A473J CHIP R 47K J 1/10W
R123 RK73GB2A104J CHIP R 100K J 1/10W
R124-126 RK73GB2A473J CHIP R 47K J 1/10W
R127,128 RK73GB2A101J CHIP R 100 J 1/10W
R129-131 RK73GB2A103J CHIP R 10K J 1/10W
R132 RK73GB2A000J CHIP R 0.0 J 1/10W
R133 RK73GB2A153J CHIP R 15K J 1/10W
R134 RK73GB2A102J CHIP R 1.0K J 1/10W
R135-139 RK73GB2A101J CHIP R 100 J 1/10W
R140 RK73GB2A473J CHIP R 47K J 1/10W
R141 RK73GB2A102J CHIP R 1.0K J 1/10W
R142-147 RK73GB2A101J CHIP R 100 J 1/10W
R148,149 RK73GB2A103J CHIP R 10K J 1/10W
R150-152 RK73GB2A473J CHIP R 47K J 1/10W
R153-155 RK73GB2A103J CHIP R 10K J 1/10W X1
R154 RK73GB2A103J CHIP R 10K J 1/10W K1E3
R154,155 RK73GB2A103J CHIP R 10K J 1/10W E2M1
R154,155 RK73GB2A103J CHIP R 10K J 1/10W
KR1E1
R157 RK73GB2A103J CHIP R 10K J 1/10W KM1K1
R157 RK73GB2A303J CHIP R 30K J 1/10W X1
R157 RK73GB2A332J CHIP R 3.3K J 1/10W
E1E2E3
R159-161 RK73GB2A103J CHIP R 10K J 1/10W E3
R159,160 RK73GB2A103J CHIP R 10K J 1/10W K1
R160 RK73GB2A103J CHIP R 10K J 1/10W K
R160,161 RK73GB2A103J CHIP R 10K J 1/10W M1X1
R160,161 RK73GB2A103J CHIP R 10K J 1/10W
R1E1E2
R162 RK73GB2A101J CHIP R 100 J 1/10W
R163 RK73GB2A102J CHIP R 1.0K J 1/10W
R164 RK73GB2A222J CHIP R 2.2K J 1/10W X1
R164,165 RK73GB2A222J CHIP R 2.2K J 1/10W
E2M1K1
R164,165 RK73GB2A222J CHIP R 2.2K J 1/10W E3
R164,165 RK73GB2A222J CHIP R 2.2K J 1/10W
KR1E1
R166 RK73GB2A101J CHIP R 100 J 1/10W
R167 RK73GB2A103J CHIP R 10K J 1/10W
R168-177 RK73GB2A101J CHIP R 100 J 1/10W
R178 RK73GB2A471J CHIP R 470 J 1/10W
R179,180 RK73GB2A104J CHIP R 100K J 1/10W
R181-184 RK73GB2A473J CHIP R 47K J 1/10W
R185 RK73GB2A472J CHIP R 4.7K J 1/10W
R186-188 RK73GB2A104J CHIP R 100K J 1/10W
R189,190 RK73GB2A473J CHIP R 47K J 1/10W
R191,192 RK73GB2A101J CHIP R 100 J 1/10W
R193 RK73GB2A103J CHIP R 10K J 1/10W
R194,195 RK73GB2A101J CHIP R 100 J 1/10W
R197 RK73GB2A472J CHIP R 4.7K J 1/10W
R200 RK73GB2A104J CHIP R 100K J 1/10W
R201 RK73EB2E2R2J CHIP R 2.2 J 1/4W
R204 RK73GB2A104J CHIP R 100K J 1/10W
R205 RK73GB2A102J CHIP R 1.0K J 1/10W
R206,207 RK73GB2A103J CHIP R 10K J 1/10W
R208,209 RK73GB2A101J CHIP R 100 J 1/10W
R210,211 RK73GB2A102J CHIP R 1.0K J 1/10W
R212-215 RK73GB2A000J CHIP R 0.0 J 1/10W
R216-219 RK73GB2A101J CHIP R 100 J 1/10W
R220,221 RK73GB2A331J CHIP R 330 J 1/10W
R222 RK73GB2A000J CHIP R 0.0 J 1/10W
R251 RK73GB2A223J CHIP R 22K J 1/10W
R252 RK73GB2A102J CHIP R 1.0K J 1/10W
R253 RK73GB2A000J CHIP R 0.0 J 1/10W
R255-257 RK73GB2A222J CHIP R 2.2K J 1/10W
E2M1K1
R255-257 RK73GB2A222J CHIP R 2.2K J 1/10W E3
R255-257 RK73GB2A222J CHIP R 2.2K J 1/10W
KR1E1
R301 RK73GB2A333J CHIP R 33K J 1/10W
R302 RK73GB2A272J CHIP R 2.7K J 1/10W
R303 RK73GB2A221J CHIP R 220 J 1/10W
R304 RK73GB2A223J CHIP R 22K J 1/10W
R305 RK73GB2A432J CHIP R 4.3K J 1/10W
R306 RK73GB2A100J CHIP R 10 J 1/10W
R307 RK73GB2A331J CHIP R 330 J 1/10W
R308-311 RK73GB2A470J CHIP R 47 J 1/10W
R313 RK73GB2A000J CHIP R 0.0 J 1/10W
E1E2E3
R355 RK73FB2B101J CHIP R 100 J 1/8W
R356 RK73GB2A471J CHIP R 470 J 1/10W
R357 RK73GB2A223J CHIP R 22K J 1/10W
R358,359 RK73GB2A103J CHIP R 10K J 1/10W
R360 RK73GB2A223J CHIP R 22K J 1/10W
R361 RK73FB2B101J CHIP R 100 J 1/8W
R362 RK73GB2A471J CHIP R 470 J 1/10W
R363 RK73FB2B101J CHIP R 100 J 1/8W
R364 RK73GB2A471J CHIP R 470 J 1/10W
R365 RK73GB2A223J CHIP R 22K J 1/10W
R366,367 RK73GB2A103J CHIP R 10K J 1/10W
R368 RK73GB2A223J CHIP R 22K J 1/10W
R369 RK73FB2B101J CHIP R 100 J 1/8W
R370 RK73GB2A471J CHIP R 470 J 1/10W
R371 RK73FB2B101J CHIP R 100 J 1/8W
R372 RK73GB2A471J CHIP R 470 J 1/10W
ELECTRIC UNIT (X34-477x-xx)
