Kenwood DNX5280BT User Manual

8484
Return to the Top page
Audio Setting Up
Zone Control
You can select different sources for both
front and rear positions in the vehicle.
1
Touch [Zone Control].
Zone Control screen appears.
2
Touch [Dual Zone].
3
Set each source as follows.
[3] (Front Source, Rear Source)
Select the audio source for each.
[∞], [5] (Rear VOL.)
Adjusts the rear channel volume.
[Single Zone]
Touch to turn off the dual zone function.
NOTE
• When the rear speaker sound is switched, the
audio source that is output at the AV OUTPUT
terminal is also switched to the same source.
• When the dual zone function is set to on, the
following functions are not available.
• Output from the subwoofer
• Subwoofer Level/Bass Boost
(P.81)
• Equalizer Control/Space Enhancer
/
Listening Position (P.82, 84, 85)
• DSP Bypass Control
/Speaker Setup/Car
Type (DTA) Setup (P.81, 78, 79)
Space Enhancer
1
Touch [Space Enhancer].
Space Enhancer screen appears.
2
Touch [Small], [Large], or [OFF].
Each setting value indicates the
soundscape level.
NOTE
• This setting is not available during tuner source.

Kenwood DNX5280BT Specifications

General

Auto	Yes
Marine (chartplotters, sounders)	No
Map view options	2D
GPS accuracy - position	10 m
GPS accuracy - velocity	0.05 m/s
Display diagonal	6.1 \
Compatible memory cards	microSDHC, SD, SDHC
Bluetooth version	2.1+EDR
USB 2.0 ports quantity	1
Storage temperature (T-T)	-20 - 85 °C
Operating temperature (T-T)	-10 - 60 °C
Audio formats supported	AAC, MP3, WAV, WMA
Image formats supported	JPG
Video formats supported	DIVX, MPEG1, MPEG2
Product color	Black

Weight and Dimensions

Depth	159.3 mm
Width	182 mm
Height	112 mm
Weight	2200 g
