Components Description
■
ACCESSORY UNIT (X42-3280-20)
Ref. No. Part Name Description
IC3 MOS-IC Digital potentiometer
IC4 Analogue IC OP AMP
IC6 MOS-IC OP AMP
IC9 Bi-polar IC Voltage regulator
IC10 MOS-IC Inverter
IC11 ROM IC EEPROM
IC12 Analogue IC ADC
Q2~4 FET DC switch
Q5,6 Transistor RF AMP
Q13~17 FET DC switch
D5 Diode DC switch
D8 Diode Detector
OPTIONAL ACCESSORIES /
可选附件
: KXK-3 (OCXO UNIT /
OCXO 单元
)
Ref. No. Ad dress Parts No. Description
New
parts
Parts List /
零件表
✽
New Parts.
✽
B62-2022-00 INSTRUCTION MANUAL M
✽
B62-2162-00 INSTRUCTION MANUAL M2
E31-3269-15 LEAD WIRE WITH MINIPIN PLUG
✽
E37-1405-05 FLAT CABLE
✽
E37-1406-05 LEAD WIRE WITH CONNECTOR
N67-3008-48 PAN HEAD SEMS SCREW
C1-4 CK73GB1H471K CHIP C 470PF K
C5 CK73GB1H104K CHIP C 0.10UF K
C6 CK73GB1H471K CHIP C 470PF K
C7 CK73GB1H102K CHIP C 1000PF K
C8 CK73GB1H471K CHIP C 470PF K
C10 CK73GB1H471K CHIP C 470PF K
C12 CK73GB1H103K CHIP C 0.010UF K
C13 CK73GB1H104K CHIP C 0.10UF K
C14 CC73GCH1H090B CHIP C 9.0PF B
C16-19 CK73GB1H104K CHIP C 0.10UF K
C20 CK73GB1H471K CHIP C 470PF K
C21,22 CK73GB1H104K CHIP C 0.10UF K
C24 CC73GCH1H030B CHIP C 3.0PF B
C26 CK73GB1H471K CHIP C 470PF K
C27 CK73GB1H103K CHIP C 0.010UF K
C28 CK73GB1H104K CHIP C 0.10UF K
C29 CC73GCH1H060B CHIP C 6.0PF B
C30
✽
CE32AU1C330M CHIP EL 33UF 16WV
C31 CK73GB1H104K CHIP C 0.10UF K
C33 CK73GB1H104K CHIP C 0.10UF K
C35 CK73GB1H104K CHIP C 0.10UF K
C36-39 CK73GB1H471K CHIP C 470PF K
C46 CC73GCH1H820J CHIP C 82PF J
C47 CK73GB1H104K CHIP C 0.10UF K
C54 CK73GB1H104K CHIP C 0.10UF K
C56 CK73GB1H104K CHIP C 0.10UF K
C59 CK73GB1H104K CHIP C 0.10UF K
C61 CC73GCH1H560J CHIP C 56PF J
C62 CK73GB1H104K CHIP C 0.10UF K
C63 CC73GCH1H391J CHIP C 390PF J
C64 CK73GB1H104K CHIP C 0.10UF K
C71 CC73GCH1H101J CHIP C 100PF J
C72 CC73GCH1H270J CHIP C 27PF J
C73 CC73GCH1H101J CHIP C 100PF J
C80 CK73GB1H104K CHIP C 0.10UF K
C81 CC73GCH1H050B CHIP C 5.0PF B
C82 CC73GCH1H1R5B CHIP C 1.5PF B
C84 CC73GCH1H220J CHIP C 22PF J
C86 CK73GB1E105K CHIP C 1.0UF K
C87,88 CK73GB1H471K CHIP C 470PF K
C89 CC73GCH1H101J CHIP C 100PF J
C90 CK73GB1H104K CHIP C 0.10UF K
C91 CK73GB1H103K CHIP C 0.010UF K
C93 CK73GB1H104K CHIP C 0.10UF K
C94 CK73GB1H103K CHIP C 0.010UF K
C95,96
✽
CS77CC1C100M CHIP TNTL 10UF 16WV
C97 CK73GB1H104K CHIP C 0.10UF K
C99 CK73GB1H103K CHIP C 0.010UF K
C100,101 CK73GB1H104K CHIP C 0.10UF K
C102,103 CK73GB1H471K CHIP C 470PF K
C104 CK73GB1H103K CHIP C 0.010UF K
C105 CK73GB1H104K CHIP C 0.10UF K
KXK-3
ACCESSORY UNIT (X42-3280-20)
Desti-
nation
Ref. No. Ad dress Parts No. Description
New
parts
Desti-
nation
元件说明
■ ACCESSORY 单元 (X42-3280-20)
有关号码 零 件 名 称 说 明
IC3 MOS-IC 数字电位计
IC4 模拟 IC OP 放大器
IC6 MOS-IC OP 放大器
IC9 双极 IC 稳压器
IC10 MOS-IC 变换器
IC11 ROM IC EEPROM
IC12 模拟 IC ADC
Q2
~
4
场效应管 直流开关
Q5,6 晶体管 RF 放大器
Q13
~
17
场效应管 直流开关
D5
二极管 直流开关
D8
二极管
检测器
