Kenwood NXR-800 Service Manual Supplement

NXR-800
29
PARTS LIST
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
TX UNIT (X56-3120-XX)
C137 CK73GB1H103K CHIP C 0.010UF K
C138 CC73GCH1H0R5B CHIP C 0.5PF B
C139 CC73GCH1H020B CHIP C 2.0PF B
C140,141 CC73GCH1H471J CHIP C 470PF J
C142 CC73GCH1H070B CHIP C 7.0PF B K2
C142 CC73GCH1H090B CHIP C 9.0PF B K
C143 CC73GCH1H080D CHIP C 8.0PF D K2
C143 CC73GCH1H100D CHIP C 10PF D K
C145 CC73GCH1H070B CHIP C 7.0PF B K2
C145 CC73GCH1H100C CHIP C 10PF C K
C146 CC73GCH1H471J CHIP C 470PF J
C147 CC73GCH1H0R5B CHIP C 0.5PF B
C148 CC73GCH1H120J CHIP C 12PF J K2
C148 CC73GCH1H150J CHIP C 15PF J K
C149 CK73GB1H103K CHIP C 0.010UF K
C151 CE32CL1V100M CHIP EL 10UF 35WV
C152 CC73GCH1H471J CHIP C 470PF J
C153 CC73GCH1H080D CHIP C 8.0PF D K2
C153 CC73GCH1H100D CHIP C 10PF D K
C154 CS77CC1C330M CHIP TNTL 33UF 16WV
C156,157 CC73GCH1H471J CHIP C 470PF J
C158 CS77CC1C330M CHIP TNTL 33UF 16WV
C160 CC73GCH1H471J CHIP C 470PF J
C161 CE32BM1E470M CHIP EL 47UF 25WV
C162,163 CC73GCH1H471J CHIP C 470PF J
C164 CC73GCH1H070D CHIP C 7.0PF D
C166 CC73GCH1H060D CHIP C 6.0PF D
C167 CC73GCH1H070D CHIP C 7.0PF D
C168 CC73GCH1H030C CHIP C 3.0PF C
C169,170 CC73GCH1H471J CHIP C 470PF J
C171 CK73GB1H103K CHIP C 0.010UF K
C172 CK73GB1H471K CHIP C 470PF K
C173,174 CC73GCH1H471J CHIP C 470PF J
C175 CC73GCH1H070D CHIP C 7.0PF D
C176 CC73GCH1H471J CHIP C 470PF J
C177-180 CK73GB1H104K CHIP C 0.10UF K
C181 CC73GCH1H471J CHIP C 470PF J
C182 CC73GCH1H080D CHIP C 8.0PF D
C183 CC73GCH1H080B CHIP C 8.0PF B K2
C183 CC73GCH1H100D CHIP C 10PF D K
C186 CC73GCH1H100D CHIP C 10PF D
C187 C93-0912-05 CHIP C 100UF M
C188 CC73GCH1H471J CHIP C 470PF J
C189 CC73GCH1H060B CHIP C 6.0PF B K2
C189 CC73GCH1H080B CHIP C 8.0PF B K
C190 CC73GCH1H0R5B CHIP C 0.5PF B
C191 CC73GCH1H020B CHIP C 2.0PF B
C192 CC73GCH1H471J CHIP C 470PF J
C193 CC73GCH1H070B CHIP C 7.0PF B K2
C193 CC73GCH1H090B CHIP C 9.0PF B K
C194 CC73GCH1H080B CHIP C 8.0PF B K2
C194 CC73GCH1H100C CHIP C 10PF C K
C195 CC73GCH1H0R5B CHIP C 0.5PF B
C196-198 CC73GCH1H471J CHIP C 470PF J
C201 CC73GCH1H471J CHIP C 470PF J
C202 CC73GCH1H060D CHIP C 6.0PF D K2
C202 CC73GCH1H070D CHIP C 7.0PF D K
C203,204 CC73GCH1H471J CHIP C 470PF J
C205 CK73GB1H103K CHIP C 0.010UF K
C206 CC73GCH1H471J CHIP C 470PF J
C207 CC73GCH1H070D CHIP C 7.0PF D
C208,209 CC73GCH1H471J CHIP C 470PF J
C210 CC73GCH1H050C CHIP C 5.0PF C K2
C210,211 CC73GCH1H060D CHIP C 6.0PF D K
C211 CC73GCH1H040C CHIP C 4.0PF C K2
C212-215 CC73GCH1H471J CHIP C 470PF J K
C212,213 CC73GCH1H471J CHIP C 470PF J K2
C214 CC73GCH1H100D CHIP C 10PF D K2
C215 CC73GCH1H471J CHIP C 470PF J K2
C216 CK73GB1H103K CHIP C 0.010UF K
C217 CC73GCH1H100D CHIP C 10PF D K
C217 CC73GCH1H471J CHIP C 470PF J K2
C218 CC73GCH1H120J CHIP C 12PF J K
C218 CC73GCH1H180J CHIP C 18PF J K2
C219 CC73GCH1H471J CHIP C 470PF J
C220 CK73GB1H104K CHIP C 0.10UF K
C221 CC73GCH1H0R5C CHIP C 0.5PF C K2
C221 CC73GCH1H030C CHIP C 3.0PF C K
C223 CC73GCH1H471J CHIP C 470PF J
C224 CK73GB1H473K CHIP C 0.047UF K
C225,226 CC73GCH1H471J CHIP C 470PF J
C227 CK73GB1H103K CHIP C 0.010UF K
C228 CC73GCH1H471J CHIP C 470PF J
C230 CC73GCH1H471J CHIP C 470PF J
C231 CK73GB1H103K CHIP C 0.010UF K
C233 CC73GCH1H010C CHIP C 1.0PF C
C234 CC73GCH1H471J CHIP C 470PF J
C235 CK73GB1H103K CHIP C 0.010UF K
C237 CC73GCH1H471J CHIP C 470PF J
C240 CC73GCH1H221J CHIP C 220PF J
C241 CC73GCH1H820J CHIP C 82PF J
C242 CC73GCH1H330J CHIP C 33PF J
C243,244 CC73GCH1H471J CHIP C 470PF J
C245 CC73GCH1H470J CHIP C 47PF J
C246,247 CC73GCH1H471J CHIP C 470PF J
C248 CC73GCH1H151J CHIP C 150PF J
C249 CE32CL1V100M CHIP EL 10UF 35WV
C250 CK73GB1H104K CHIP C 0.10UF K
C251,252 CK73GB1H103K CHIP C 0.010UF K
C253 CE32CL1V100M CHIP EL 10UF 35WV
C254 CK73GB1H104K CHIP C 0.10UF K
C255,256 CK73GB1H103K CHIP C 0.010UF K
C257-260 CK73GB1H104K CHIP C 0.10UF K
C263 CC73GCH1H390J CHIP C 39PF J
C265 CC73GCH1H680J CHIP C 68PF J
C267 CC73GCH1H390J CHIP C 39PF J
C269-272 CK73GB1H104K CHIP C 0.10UF K
C275 CC73GCH1H471J CHIP C 470PF J
C276 CC73GCH1H271J CHIP C 270PF J
C277 CC73GCH1H471J CHIP C 470PF J
C278 CC73GCH1H391J CHIP C 390PF J
C279 CC73GCH1H471J CHIP C 470PF J
C280 CC73GCH1H271J CHIP C 270PF J
C281 CC73GCH1H471J CHIP C 470PF J
C282-285 CK73GB1H104K CHIP C 0.10UF K
C286 CK73GB1H103K CHIP C 0.010UF K
C287 CK73GB1H104K CHIP C 0.10UF K
C301 CS77CA1C2R2M CHIP TNTL 2.2UF 16WV
C302 CC73GCH1H100D CHIP C 10PF D
C303 CK73GB1H103K CHIP C 0.010UF K
