Kenwood NXR-800 Service Manual Supplement

NXR-800
31
PARTS LIST
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
TX UNIT (X56-3120-XX)
C492-495 CK73GB1H104K CHIP C 0.10UF K
C496 CC73GCH1H221J CHIP C 220PF J
C497 CK73GB1H104K CHIP C 0.10UF K
C498 CC73GCH1H121J CHIP C 120PF J
C499 CK73GB1H104K CHIP C 0.10UF K
C500 CC73GCH1H471J CHIP C 470PF J
C501,502 CK73GB1H104K CHIP C 0.10UF K
C503 CC73GCH1H470J CHIP C 47PF J
C504 CC73GCH1H010C CHIP C 1.0PF C
C505,506 CK73GB1H104K CHIP C 0.10UF K
C507,508 CC73GCH1H331J CHIP C 330PF J
C509,510 CK73GB1H104K CHIP C 0.10UF K
C511 CC73GCH1H470J CHIP C 47PF J
C512 CC73GCH1H471J CHIP C 470PF J
C513 CC73GCH1H010C CHIP C 1.0PF C
C514 CC73GCH1H121J CHIP C 120PF J
C515 CC73GCH1H030C CHIP C 3.0PF C
C516,517 CK73GB1H104K CHIP C 0.10UF K
C519 CK73GB1H104K CHIP C 0.10UF K
C520 CC73GCH1H221J CHIP C 220PF J
C521-527 CK73GB1H104K CHIP C 0.10UF K
C529-532 CK73GB1H104K CHIP C 0.10UF K
C533 CC73GCH1H471J CHIP C 470PF J
C534-537 CK73GB1H104K CHIP C 0.10UF K
C538 CC73GCH1H471J CHIP C 470PF J
C539 CK73GB1H104K CHIP C 0.10UF K
C541,542 CC73GCH1H100D CHIP C 10PF D
C543-547 CK73GB1H104K CHIP C 0.10UF K
C548 CC73GCH1H471J CHIP C 470PF J
C549-552 CK73GB1H104K CHIP C 0.10UF K
C554-556 CK73GB1H104K CHIP C 0.10UF K
C557 CC73GCH1H030C CHIP C 3.0PF C
C558,559 CK73GB1H104K CHIP C 0.10UF K
C562 CK73GB1H104K CHIP C 0.10UF K
C563 CC73GCH1H121J CHIP C 120PF J
C564 CC73GCH1H470J CHIP C 47PF J
C565 CK73GB1H104K CHIP C 0.10UF K
C568 CC73GCH1H221J CHIP C 220PF J
C569 CC73GCH1H471J CHIP C 470PF J
C570 CC73GCH1H010C CHIP C 1.0PF C
C571 CC73GCH1H331J CHIP C 330PF J
C573,574 CC73GCH1H331J CHIP C 330PF J
C575,576 CC73GCH1H180J CHIP C 18PF J
C577,578 CC73GCH1H331J CHIP C 330PF J
C601-605 CK73GB1H104K CHIP C 0.10UF K
C610 CK73GB1H104K CHIP C 0.10UF K
C612,613 CK73GB1H104K CHIP C 0.10UF K
C614 CC73GCH1H100D CHIP C 10PF D
C616 CC73GCH1H270J CHIP C 27PF J
C619 CC73GCH1H100D CHIP C 10PF D
C620-623 CK73GB1H104K CHIP C 0.10UF K
C624-627 CC73GCH1H560J CHIP C 56PF J
C628-631 CK73GB1H104K CHIP C 0.10UF K
C632-634 CK73GB1H103K CHIP C 0.010UF K
C635,636 CK73GB1H104K CHIP C 0.10UF K
C637 CK73GB1H103K CHIP C 0.010UF K
C638 CC73GCH1H470J CHIP C 47PF J
C639 CC73GCH1H180J CHIP C 18PF J
C640 CC73GCH1H181J CHIP C 180PF J
C641 CC73GCH1H331J CHIP C 330PF J
C642 CC73GCH1H221J CHIP C 220PF J
C643 CC73GCH1H471J CHIP C 470PF J
C645 CC73GCH1H471J CHIP C 470PF J
C656,657 CK73GB1H103K CHIP C 0.010UF K
C658 CK73GB1H104K CHIP C 0.10UF K
C659,660 CK73GB1H103K CHIP C 0.010UF K
C661 CK73FB0J106K CHIP C 10UF K
C662,663 CK73GB1H104K CHIP C 0.10UF K
C703 CK73GB1H104K CHIP C 0.10UF K
C704 CK73FB0J106K CHIP C 10UF K
C707 CK73GB1H102K CHIP C 1000PF K
C708 CK73GB1H104K CHIP C 0.10UF K
C709 CE32CL1V100M CHIP EL 10UF 35WV
C710 CK73GB1H104K CHIP C 0.10UF K
C711 CK73GB1H103K CHIP C 0.010UF K
C712,713 CC73GCH1H471J CHIP C 470PF J
C714 CK73GB1H103K CHIP C 0.010UF K
C715 CE32CL1V100M CHIP EL 10UF 35WV
C716 CK73GB1H103K CHIP C 0.010UF K
C717,718 CC73GCH1H471J CHIP C 470PF J
C719 CK73GB1H103K CHIP C 0.010UF K
C720,721 CE32CL1V100M CHIP EL 10UF 35WV
C722 CK73GB1H103K CHIP C 0.010UF K
C723,724 CC73GCH1H471J CHIP C 470PF J
C725 CK73GB1H103K CHIP C 0.010UF K
C801-803 CK73GB1H104K CHIP C 0.10UF K
C804 CC73GCH1H471J CHIP C 470PF J
C805 CK73GB1H104K CHIP C 0.10UF K
C806 CE32CL1V100M CHIP EL 10UF 35WV
C807 CK73FB1C105K CHIP C 1.0UF K
C808,809 CK73GB1H104K CHIP C 0.10UF K
C810 CC73GCH1H471J CHIP C 470PF J
C811 CK73GB1H104K CHIP C 0.10UF K
C812 CK73GB1H103K CHIP C 0.010UF K
C813 CC73GCH1H471J CHIP C 470PF J
C814 CK73GB1H104K CHIP C 0.10UF K
C816 CE32CL1V100M CHIP EL 10UF 35WV
C817 CK73GB1H103K CHIP C 0.010UF K
C818 CE32CL1V100M CHIP EL 10UF 35WV
C819 CC73GCH1H471J CHIP C 470PF J
C820,821 CK73GB1H104K CHIP C 0.10UF K
C822 CK73GB1H103K CHIP C 0.010UF K
C823,824 CC73GCH1H471J CHIP C 470PF J
C825 CK73GB1H103K CHIP C 0.010UF K
C826 CC73GCH1H471J CHIP C 470PF J
C827 CK73GB1H103K CHIP C 0.010UF K
C848 C92-0904-05 OS-CON 22UF 35WV
C850 CK73GB1H103K CHIP C 0.010UF K
C856 CE32AU1E100M CHIP EL 10UF 25WV
C857 CK73GB1H103K CHIP C 0.010UF K
C858,859 CC73GCH1H471J CHIP C 470PF J
C860 CK73GB1H103K CHIP C 0.010UF K
C885 CK73GB1H104K CHIP C 0.10UF K
C886 CC73GCH1H270J CHIP C 27PF J
C887 CC73GCH1H100D CHIP C 10PF D
C888 CC73GCH1H270J CHIP C 27PF J
C889 CK73GB1H104K CHIP C 0.10UF K
C890 CK73GB1E105K CHIP C 1.0UF K
C894,895 CK73GB1H103K CHIP C 0.010UF K
C896 CC73GCH1H100D CHIP C 10PF D
