Kenwood RXD-M32MD User Manual

RXD-M32MD
54
PARTS LIST
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
C1409 CK73FF1C105Z CHIP C 1.0UF Z
C1411 CK73GB1C223K CHIP C 0.022UF K
C1501 CK73FF1C105Z CHIP C 1.0UF Z
C1502 C93-0044-08 CERAMIC 330PF J
C1503 CK73EB1C334K CHIP C 0.33UF K
C1505 CK73GB1C473K CHIP C 0.047UF K
C1506 CC73GCH1H101J CHIP C 100PF J
C1507 CK73GB1C473K CHIP C 0.047UF K
C1509 CC73GCH1H101J CHIP C 100PF J
C1601-604 CC73GSL1H821J CHIP C 820PF J
C1606 C92-0172-08 CHIP-C 10UF K
C1607 CK73FF1C105Z CHIP C 1.0UF Z
C1610 C92-0171-08 CHIP-C 4.7UF K
C1611,612 CK73GB1H562K CHIP C 5600PF K
C1613 CK73GB1E153K CHIP C 0.015UF K
C1615 CK73GB1E153K CHIP C 0.015UF K
C1616 C92-0151-08 ELECTRO 100UF 10WV
C1619 C93-0044-08 CERAMIC 330PF J
C1655 CK73GB1E153K CHIP C 0.015UF K
C1700,701 C92-0162-08 ELECTRO 47UF 4WV
C1702 CK73GB1H102K CHIP C 1000PF K
C1703 CK73GF1E104Z CHIP C 0.10UF Z
C1704 C92-0162-08 ELECTRO 47UF 4WV
C1705 CK73GF1E104Z CHIP C 0.10UF Z
C1706 CK73FF1H103Z CHIP C 0.010UF Z
C1707 CK73FF1C105Z CHIP C 1.0UF Z
C1708,709 CK73FF1H103Z CHIP C 0.010UF Z
C1710 C92-0173-08 ELECTRO 10UF 16WV
C1711 C92-0162-08 ELECTRO 47UF 4WV
C1712 C92-0173-08 ELECTRO 10UF 16WV
C1713 CK73FF1H103Z CHIP C 0.010UF Z
C1714 CK73FF1C105Z CHIP C 1.0UF Z
C1715 CK73FB1C104K CHIP C 0.10UF K
C1716 C92-0162-08 ELECTRO 47UF 4WV
C1741 CC73GSL1H821J CHIP C 820PF J
C1750 CC73GSL1H821J CHIP C 820PF J
C1800 C92-0174-08 ELECTRO 220UF 4WV
C1801,802 C92-0172-08 CHIP-C 10UF K
C1803 C92-0151-08 ELECTRO 100UF 10WV
C1804 CK73EF1C225Z CHIP C 2.2UF Z
C1805 CK73FF1C105Z CHIP C 1.0UF Z
CN1101 ✽ E40-8618-08 FLAT CABLE CONNECTOR,28P
CN1300 ✽ E40-8619-08 PIN ASSY 2P
CN1401 E40-8211-08 FLAT CABLE CONNECTOR,5P
CN1402 ✽ E40-8620-08 FLAT CABLE CONNECTOR,6P
CN1501 E40-8371-08 FLAT CABLE CONNECTOR,28P
CN1502 ✽ E40-8641-08 PIN ASSY
CN1931 E40-8211-08 FLAT CABLE CONNECTOR
CN1932 ✽ E40-8617-08 FLAT CABLE CONNECTOR
PCB-E 3C ✽ J70-1449-08 PC BOARD
L1100 L90-0100-08 COIL
L1101 L90-0099-08 COIL
L1200 L90-0301-08 COIL
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
*
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
R60 RK73GB1J101J CHIP R 100 J 1/16W
R61 ,62 RK73GB1J2R2J CHIP R 2.2 J 1/16W
R63 RK73GB1J473J CHIP R 47K J 1/16W
R65 ,66 RK73GB1J104J CHIP R 100K J 1/16W
R67 ,68 RK73GB1J101J CHIP R 100 J 1/16W
VR1 R32-0018-05 SEMI FIXED VARIABLE RESISTOR
W1 R92-0679-05 CHIP R 0 OHM
D1 ,2 MA111 DIODE
IC1 CXA1821M ANALOGUE IC
IC2 ✽ BA5974FP ANALOGUE IC
IC3 ✽ CXD3017Q MOS-IC
IC4 HD74UH08 MOS-IC
Q1 2SA1576A(R,S) TRANSISTOR
Q2 DTA124EUA DIGITAL TRANSISTOR
Q2 UN5112 DIGITAL TRANSISTOR
Q3 2SC4213(B) TRANSISTOR
Q4 -6 ✽ 2SK1580 FET
Q4 -6 2SK1958 FET
C1100 C92-0171-08 CHIP-C 4.7UF K
C1101 C93-0033-08 CERAMIC 1UF K
C1102 CK73FF1C105Z CHIP C 1.0UF Z
C1103 CK73FB1H273K CHIP C 0.027UF K
C1104 CK73FB1H333K CHIP C 0.033UF K
C1105 CK73GB1H332K CHIP C 3300PF K
C1106 C93-0033-08 CERAMIC 1UF K
C1107 CK73GB1C333K CHIP C 0.033UF K
C1108 CK73FB1C474K CHIP C 0.47UF K
C1109 C93-0033-08 CERAMIC 1UF K
C1110 CK73FB1H472K CHIP C 4700PF K
C1111 CK73FB1C474K CHIP C 0.47UF K
C1112 C93-0044-08 CERAMIC 330PF J
C1113-117 C93-0034-08 CERAMIC 270PF J
C1118 CK73FF1C105Z CHIP C 1.0UF Z
C1119 C93-0033-08 CERAMIC 1UF K
C1200 CK73FF1C105Z CHIP C 1.0UF Z
C1201 C92-0172-08 CHIP-C 10UF K
C1202,203 CK73FF1C105Z CHIP C 1.0UF Z
C1204 CK73GB1C473K CHIP C 0.047UF K
C1205 CK73FF1C105Z CHIP C 1.0UF Z
C1206 CK73GB1H122K CHIP C 1200PF K
C1207 CK73FF1C105Z CHIP C 1.0UF Z
C1208,209 CC73GCH1H120J CHIP C 12PF J
C1210 CC73GCH1H220J CHIP C 22PF J
C1300 CC73FCH1H470J CHIP C 47PF J
C1301 CK73GB1C273K CHIP C 0.027UF K
C1302 C92-0172-08 CHIP-C 10UF K
C1303 CK73FF1C105Z CHIP C 1.0UF Z
C1304 CC73FCH1H221J CHIP C 220PF J
C1402 CK73GB1C223K CHIP C 0.022UF K
C1403 CK73GF1E104Z CHIP C 0.10UF Z
C1404 CK73GB1C473K CHIP C 0.047UF K
C1405,406 CK73GB1H681K CHIP C 680PF K
C1407 CK73GB1C473K CHIP C 0.047UF K
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
&
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
MD UNIT
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299

Kenwood RXD-M32MD Specifications

Amplifier Section

effective output power during STEREO operation	20 W + 20 W
rated output power during STEREO operation	15 W + 15 W
wow and flutter	0.2 %

Tuner Section

FM tuning frequency range	87.5 MHz ~ 108 MHz
MW (AM) tuning frequency range (for U.K. and Europe)	531 kHz ~ 1, 602 kHz
MW (AM) tuning frequency range (for other countries)	530 kHz ~ 1, 610 kHz

General

power consumption	60 W
dimensions (W x H x D)	180 mm x 239 mm x 305 mm
weight (net)	5.7 kg

Speaker Section

woofer size	100 mm
tweeter size	50 mm
impedance	6 Ω

MD Recorder Section

dimensions (W x H x D)	150 mm x 234 mm x 197 mm
weight (net)	2.4 kg
maximum input level	30 W
