Kenwood RXD-M32MD User Manual

RXD-M32MD
55
PARTS LIST
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
R1512 RK73FB2A470J CHIP R 47 J 1/10W
R1513 RK73GB1J822J CHIP R 8.2K J 1/16W
R1515,516 RK73GB1J182J CHIP R 1.8K J 1/16W
R1517,518 RK73GB1J470J CHIP R 47 J 1/16W
R1520 RK73GB1J473J CHIP R 47K J 1/16W
R1521 RK73GB1J121J CHIP R 120 J 1/16W
R1523 RK73GB1J473J CHIP R 47K J 1/16W
R1524,525 R92-1824-08 JUMPER R 0 J 1/10W
R1526 RK73GB1J682J CHIP R 6.8K J 1/16W
R1527 RK73GB1J473J CHIP R 47K J 1/16W
R1528 R92-1824-08 JUMPER R 0 J 1/10W
R1529 RK73GB1J221J CHIP R 220 J 1/16W
R1530 R92-1823-08 JUMPER R 0 J 1/16W
R1532 RK73GB1J332J CHIP R 3.3K J 1/16W
R1533-536 RK73GB1J102J CHIP R 1.0K J 1/16W
R1537,538 RK73GB1J221J CHIP R 220 J 1/16W
R1539 RK73GB1J121J CHIP R 120 J 1/16W
R1540 R92-1824-08 JUMPER R 0 J 1/10W
R1551-553 R92-1823-08 JUMPER R 0 J 1/16W
R1600,601 RK73GB1J682J CHIP R 6.8K J 1/16W
R1605,606 ✽ R92-1949-08 CHIP R 10K F 1/16W
R1612 ✽ R92-1950-08 CHIP R 150K F 1/16W
R1614 ✽ R92-1947-08 CHIP R 100K F 1/16W
R1616,617 RK73GB1J103J CHIP R 10K J 1/16W
R1618 RK73GB1J153J CHIP R 15K J 1/16W
R1620 RK73GB1J153J CHIP R 15K J 1/16W
R1621 RK73GB1J682J CHIP R 6.8K J 1/16W
R1622,623 RK73GB1J223J CHIP R 22K J 1/16W
R1624 RK73GB1J682J CHIP R 6.8K J 1/16W
R1701 RK73GB1J393J CHIP R 39K J 1/16W
R1702 RK73GB1J303J CHIP R 30K J 1/16W
R1703 ✽ R92-1951-08 CHIP R 1K F 1/16W
R1704 RK73GB1J332J CHIP R 3.3K J 1/16W
R1705 RK73GB1J821J CHIP R 820 J 1/16W
R1706 RK73GB1J393J CHIP R 39K J 1/16W
R1707 RK73GB1J105J CHIP R 1.0M J 1/16W
R1708 RK73GB1J102J CHIP R 1.0K J 1/16W
R1709 RK73GB1J393J CHIP R 39K J 1/16W
R1710 RK73GB1J684J CHIP R 680K J 1/16W
R1711 RK73FB2A120J CHIP R 12 J 1/10W
R1712 RK73GB1J273J CHIP R 27K J 1/16W
R1714 RK73FB2A120J CHIP R 12 J 1/10W
R1716 RK73GB1J104J CHIP R 100K J 1/16W
R1801 RK73GB1J271J CHIP R 270 J 1/16W
R1802 ✽ R92-1952-08 CHIP R 56K F 1/16W
R1803 ✽ R92-1953-08 CHIP R 33K F 1/16W
R1804 RK73GB1J391J CHIP R 390 J 1/16W
R1805 RK73GB1J271J CHIP R 270 J 1/16W
R1806 RK73EB2B1R0J CHIP R 1 J 1/8W
R1807 RK73GB1J273J CHIP R 27K J 1/16W
R1808 RK73GB1J182J CHIP R 1.8K J 1/16W
R1809 RK73EB2B1R0J CHIP R 1 J 1/8W
R1811 RK73EB2B1R0J CHIP R 1 J 1/8W
R1930 RK73FB2A391J CHIP R 390 J 1/10W
R1931 RK73FB2A561J CHIP R 560 J 1/10W
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
)
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
L1201 L90-0100-08 COIL
L1300 L90-0322-08 COIL
L1501 L90-0303-08 COIL
L1502 L90-0301-08 COIL
L1551,552 L90-0100-08 COIL
L1553 R92-1824-08 COIL
L1554 L90-0100-08 COIL
L1600 L90-0303-08 COIL
L1701,702 L90-0099-08 COIL
LX1201 L77-2224-08 CRYSTAL RESONATOR
R1100 RK73EB2B270J CHIP R 27 J 1/8W
R1101 RK73GB1J1R0J CHIP R 1 J 1/16W
R1102 RK73GB1J103J CHIP R 10K J 1/16W
R1103 RK73GB1J394J CHIP R 390K J 1/16W
R1105 RK73GB1J122J CHIP R 1.2K J 1/16W
R1106 RK73GB1J563J CHIP R 56K J 1/16W
R1107 RK73GB1J561J CHIP R 560 J 1/16W
R1108-112
RK73GB1J223J CHIP R 22K J 1/16W
R1200,201 ✽ R92-1947-08 CHIP R 100K F 1/16W
R1202,203 ✽ R92-1948-08 CHIP R 120K F 1/16W
R1204,205 RK73GB1J823J CHIP R 82K J 1/16W
R1206,207 RK73GB1J623J CHIP R 62K J 1/16W
R1208 RK73GB1J221J CHIP R 220 J 1/16W
R1209 RK73GB1J101J CHIP R 100 J 1/16W
R1210,211 RK73GB1J221J CHIP R 220 J 1/16W
R1212 RK73GB1J470J CHIP R 47 J 1/16W
R1214 RK73GB1J103J CHIP R 10K J 1/16W
R1215 RK73GB1J105J CHIP R 1.0M J 1/16W
R1217 RK73GB1J151J CHIP R 150 J 1/16W
R1230 R92-1823-08 JUMPER R 0 J 1/16W
R1300 RK73FB2A8R2J CHIP R 8.2 J 1/10W
R1301 RK73GB1J100J CHIP R 10 J 1/16W
R1304 RK73FB2A151J CHIP R 150 J 1/10W
R1401 RK73GB1J272J CHIP R 2.7K J 1/16W
R1403 RK73GB1J471J CHIP R 470 J 1/16W
R1405 RK73GB1J104J CHIP R 100K J 1/16W
R1406 RK73GB1J103J CHIP R 10K J 1/16W
R1407,408 RK73GB1J332J CHIP R 3.3K J 1/16W
R1409 R92-1823-08 JUMPER R 0 J 1/16W
R1414 RK73GB1J224J CHIP R 220K J 1/16W
R1415 RK73GB1J102J CHIP R 1.0K J 1/16W
R1417,418 RK73GB1J102J CHIP R 1.0K J 1/16W
R1420 RK73GB1J102J CHIP R 1.0K J 1/16W
R1424 RK73GB1J473J CHIP R 47K J 1/16W
R1430 RK73GB1J103J CHIP R 10K J 1/16W
R1435 RK73GB1J103J CHIP R 10K J 1/16W
R1440 RK73GB1J101J CHIP R 100 J 1/16W
R1441 RK73GB1J473J CHIP R 47K J 1/16W
R1443 RK73GB1J102J CHIP R 1.0K J 1/16W
R1444 RK73GB1J103J CHIP R 10K J 1/16W
R1460,461 RK73GB1J103J CHIP R 10K J 1/16W
R1462 R92-1823-08 JUMPER R 0 J 1/16W
R1463 RK73GB1J103J CHIP R 10K J 1/16W
R1510 RK73GB1J102J CHIP R 1.0K J 1/16W
R1511 RK73GB1J822J CHIP R 8.2K J 1/16W
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
(
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299

Kenwood RXD-M32MD Specifications

Amplifier Section

effective output power during STEREO operation	20 W + 20 W
rated output power during STEREO operation	15 W + 15 W
wow and flutter	0.2 %

Tuner Section

FM tuning frequency range	87.5 MHz ~ 108 MHz
MW (AM) tuning frequency range (for U.K. and Europe)	531 kHz ~ 1, 602 kHz
MW (AM) tuning frequency range (for other countries)	530 kHz ~ 1, 610 kHz

General

power consumption	60 W
dimensions (W x H x D)	180 mm x 239 mm x 305 mm
weight (net)	5.7 kg

Speaker Section

woofer size	100 mm
tweeter size	50 mm
impedance	6 Ω

MD Recorder Section

dimensions (W x H x D)	150 mm x 234 mm x 197 mm
weight (net)	2.4 kg
maximum input level	30 W
