RXD-M32MD
56
PARTS LIST
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
29 2B J70-0995-08 PC BOARD LOADING
30 3A J90-0846-08 RING (LO)(S) CENTER
31 2A J99-0592-08 TABLE DISK
AB 3A N09-3345-08 SCREW (2.6X16)
AF 2A N87-3010-46 SCREW TAPPING (3X10)
40 2B S74-0075-08 SWITCH LEAF
DM 3A T42-0907-08 MOTOR CHASSIS ASSY(MB)
FM 3A T42-0875-08 MOTOR GEAR ASSY(MB)
LM 2B T42-0873-08 MOTOR ASSY LOADING
PU 3B T25-0061-08 PICKUP ASSY KSS-213C(R)
202 2C ✽ A10-3517-08 LD BASE LCHSM0089AWZZ
203 2D ✽ A11-1179-08 MD BASE LCHSM0090AWZZ
204 1C ✽ J19-6075-08 CRTRGE HLDR ASSY,LHLDX3007AWM1
205 1C ✽ D10-3941-08 SLIDER LVR ASSY,MLEVF0051AWM1
207 1C ✽ D10-3942-08 HOLDER ARM MLEVF0046AWFW
208 2C ✽ D10-3943-08 SWITCH PLATE MLEVF0047AWFW
209 2D ✽ D10-3944-08 H/A SHIFT ARM MLEVF0048AWFW
210 1C ✽ D10-3945-08 CAM PLATE LEVER,MLEVP0095AWZZ
212 1C ✽ G01-4200-08 LOADING SPRING MSPRD0132AWFJ
214 3D ✽ G02-1703-08 GRIP SPRING MSPRP0030AWFJ
215 3C ✽ G02-1704-08 SHAFT SPRING MSPRP0031AWFJ
216 1C ✽ G01-4201-08 LOADING ARM SP,MSPRT0031AWFJ
217 2C ✽ G01-4202-08 SHIFT ARM SP MSPRT0032AWFJ
218 1C ✽ D13-1992-08 LOADING GEAR(A) NGERH0085AWZZ
219 1C ✽ D13-1993-08 MID GEAR(A) NGERH0086AWZZ
220 1C ✽ D13-1994-08 MID GEAR(B) NGERH0087AWZZ
221 1C ✽ D13-1995-08 MID GEAR(C) NGERH0088AWZZ
222 2C ✽ D13-1996-08 MID GEAR(D) NGERH0089AWZZ
224 3D ✽ D13-1997-08 GRIP RACK NGERR0004AWZZ
227 3D ✽ D19-0322-08 DRIVE SCREW ASSY,NSFT0006AWM1
228 3D ✽ D10-3946-08 PICKUP GUDE SHFT,NSFTM0019AWFW
230 1D ✽ A01-3756-08 SHIELD CVR(TOP),PCOVS3029AWFW
231 2D ✽ A01-3757-08 SHIELD CVR(SIDE),PCOVS3033AWFW
232 3D ✽ A01-3758-08 SHIELD CVR(BTM),PCOVS3031AWFW
233 1D ✽ J02-1478-08 CUSHION PCUSG0045AWZZ
236 1C ✽ G01-4203-08 GND SPRING MSPRT0034AWFJ
BA ✽ N39-1415-45 SCREW(1.4X1.5) LX-BZ0040AWZZ
BB N38-2020-41 SCREW(2X2) LX-BZ0046AWZZ
BC N09-3434-08 SCREW(1.4X2.5) LX-BZ0800AFZZ
BD N39-1750-45 SCREW(1.7X5) LX-BZ0883AFZZ
BE ✽ N09-5197-08 SCREW(1.4X3) LX-JZ0020AWZZ
BF ✽ N09-5198-08 SCREW(1.7X6) LX-JZ0022AWZZ
BG ✽ N39-1445-45 SCREW(1.4X4.5) LX-JZ0024AWZZ
BH ✽ N09-5199-08 SCREW(2X3) XBPSD20P03K00
BJ ✽ N09-5200-08 SCREW(1.7X3) XSPSN17P03K00
BK N16-0014-46 WASHER(1.5X3.2X0.5)XWSSD14-05000
BL N39-1730-45 SCREW(1.7X3) LX-BZ0846AFZZ
BM N39-1450-45 SCREW(1.4X5) LX-JB0025AWZZ
CN1300 ✽ E35-2588-08 WIRE HARNESS QCNWM1044AWZZ
CN1931 E40-8211-08 CABLE CONN(5P) QCNCWXC05AFZZ
CN1932 ✽ E40-8617-08 CABLE CONN(6P) QCNCWXC06AFZZ
CW1501 3D ✽ E35-2587-08 FFC(28P) QCNWN1549AWZZ
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
™
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
R1932 RK73FB2A121J CHIP R 120 J 1/10W
R1933 RK73FB2A271J CHIP R 270 J 1/10W
SW1930 ✽ S68-0126-08 PUSH SWITCH
SW1931 ✽ S68-0127-08 PUSH SWITCH
SW1932-34
✽ S64-0049-08 LEVER SWITCH
SW1936 ✽ S64-0050-08 LEVER SWITCH
D1300 SBE803 DIODE
D1401 SB00703Q DIODE
D1402 1SS355 DIODE
IC1101 IR3R55 IC
IC1201 LR376484F IC
IC1202 IX2474AF IC
IC1300 74ACT02T IC
IC1301 FTD2005 IC
IC1302 CPH5608 IC
IC1401 ✽ IX0342AW IC
IC1402 ✽ 58X2402T IC
IC1601 ✽ M56788F IC
IC1701 ✽ UDA1347T IC
IC1702 NJM431U IC(REGULATOR)
IC1801 XC62EP32 IC
Q1402 UN2113 TRANSISTOR
Q1403 UN2213 TRANSISTOR
Q1501 UN2214 TRANSISTOR
Q1700 ✽ U2SD601AR TRANSISTOR
Q1701 UN2213 TRANSISTOR
Q1702 2SA1162G TRANSISTOR
Q1800 UN2214 TRANSISTOR
Q1801 2SA1162G TRANSISTOR
Q1802 UN2214 TRANSISTOR
Q1803 ✽ UN221N TRANSISTOR
Q1804 ✽ 2SA1242Y TRANSISTOR
Q1805 2SA1314C TRANSISTOR
Q1806 ✽ UN221N TRANSISTOR
1 2B A10-3325-08 CHASSIS
3 2A D10-3695-08 SHAFT(TABLE GUIDE)
5 3A D10-3696-08 SLED SHAFT
6 1A D12-0156-08 CAM
7 1A D13-1793-08 GEAR (P)
8 1A D13-1794-08 GEAR (C)
9 1A D13-1795-08 PULLEY (S)
10 2A D13-1796-08 GEAR (A)(S)
11 3A D13-1797-08 GEAR (B)(RP)
12 1A D16-0713-08 BELT
13 2A D23-0328-08 BEARING
15 2B E40-8051-08 PIN CONNECTOR (PC BOARD)5P
20 3A G01-3969-08 SPRING (S) COMPRESSION
25 3A J02-1179-08 PUBBER VIBRATION
26 3A J02-1180-08 PUBBER VIBRATION
27 1A J19-5768-08 HOLDER (MG)(K) ASSY
28 2A J19-5769-08 HOLDER (BU) ASSY
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
¡
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
MD MECHANISM (D40-1677-05) MDM-99D
CD MECHANISM (D40-1571-05)
