RXD-M32MD
57
PARTS LIST
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
CW1502 3D ✽ E35-2660-08 FFC(4P) QCNWN1515AWZZ
CW1931 2C,3C ✽ E35-2589-08 FFC(5P) QCNWN1512AWZZ
CW1932 3C ✽ E35-2590-08 FFC(6P) QCNWN1513AWZZ
M901 3C ✽ T42-0974-08 DISC MOTOR RMOTV0025AWZZ
M902 3C ✽ T42-0975-08 FEED MOTOR 92LMTR3167BASY
M903 2D ✽ T42-0976-08 LOADING MOTOR 92LMTR3167AASY
MDPU 2D ✽ T25-0099-08 PICKUP RCTRH8198AFZZ
MDRH 2D ✽ T30-0025-08 RECORD HEAD RCILH0113AFZZ
PWB-F 2C,3C ✽ J70-1414-08 PCB(MECHA) QPWBF0554AWZZ
SW1930 2C ✽ S68-0126-08 PUSH SWITCH QSW-P0011AWZZ
SW1931 2C ✽ S68-0127-08 PUSH SWITCH QSW-P0012AWZZ
SW1932-34
2C ✽ S64-0049-08 PUSH SWITCH QSW-M0007AWZZ
SW1936 3C ✽ S64-0050-08 PUSH SWITCH QSW-M0157AFZZ
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
£
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
HOW TO READ THE PARTS LIST
ABBREVIATION OF MODEL AND MASS PRODUCTION'S DESTINATIONS
MODEL
ABB.
Australia Canada China England Europe Germany Korea Malaysia
RXD-M32MD-L L X - H-----
RXD-M32MD-S
S
-- HTE---
-
RXD-M32MD-Y
Y
-- H1----
RXD-M32MD-LS
LS
X- H-----
MODEL
ABB.
Mexico PX/AAFES Russia Scandinavia Shanghai USA Other area
RXD-M32MD-L
L
---- --M-
RXD-M32MD-S
S
---- --M-
RXD-M32MD-Y
Y
---- --M1-
RXD-M32MD-LS
LS
---- --M-
