OPERATION: OPENING THE WORKBENCH
The Portable Clamping Workstation is packaged completely folded.
To open:
1. Place the workbench flat on the floor.
2. Grasp the openings on both sides of the table top and pull out on the release latches as
shown in figure A.
CAUTION: Do not pull the legs out when the workbench is in a closed position.
3. With the release latches pulled in, lift the table top. The four legs will drop down and lock into
place and the side supports will lift up. (figure B)
4. To lock the side supports, push out from the inside until the support locks into position (figure C).
CAUTION: Risk of Unsafe Operation. Make sure all four legs and both side supports are
locked in place.
5. After locking the side supports in place, lift the centre support section by the carrying handle
until you hear it “click” into place as shown in figure D.
6. When the centre support section is properly locked in position, the LOCK button shown in
figure E will be visible.
CAUTION: Risk of Unsafe Operation. Make sure the centre support section is locked in place.
