Keter PREMIER 757 - Door Assembly; Door Frame Preparation Steps; Door Hinge Attachment Steps

32
DOOR ASSEMBLY | MONTAGE DE LA PORTE | ARMADO DE LA PUERTA | MONTAGE DER TÜR |
DEURMONTAGE | MONTAGGIO DELLA PORTA | MONTAGEM DA PORTA
43
FCL
FCR
(x1)
FCR
FCR
FFD
(x2) FP1 (x1)
FP1
FP2
(x1)
FP2
FP2
CLICK
CLICK
FCL (x1)
44
MODHA (x1)
MODHA
MODHB
(x1)
s45m (x4) sn6 (x4)
1
2
s45m x2
sn6 x2
MODHB
MODHB
7/16”
11mm
