Parts List
Helpful advice before you begin:
1. We suggest you spend a short time reading
through this leaet and then follow the
simple step by step instructions.
2. Do not discard any of the packaging until
you have checked that you have all the
parts and the pack of ttings.
3. Assemble this product on a soft surface.
4. To ensure an easier assembly, we strongly
advise that all ttings are only nger
tightened during initial assembly. Only
upon completion of the assembly should
all xing points be fully tightened.
5. Keep ttings out of children’s reach.
6. Do not use any other tools other than
those recommended to build this product.
7. In the unlikely event that this product has
missing or damaged parts, please visit our
website www.kettler.co.uk
Do not discard any of the packaging
until you have checked that you have
all the parts and the pack of xings.
Part Description Qty
A Frame 1
B
Protective Cover - with 3
part supporting rod
1
C Wall Bracket 1 1
D Wall Bracket 2 1
E Bolt M6x55 1
F Bolt M6x35 1
G Nut 2
H Alen Key 1
I Spanner 1
J Card Drilling Template 1
TOP
DRILLING TEMPLATE
Wall xings are not included. Please visit your local DIY centre/hardware store to
purchase appropriate xings for the type of wall you wish to attach the parasol to.
To Next Page
