Page 4
Find us at www.keysight.com
Front Panel at a Glance
Rear Panel at a Glance
Label Description
1 USB port
2 On/Standby switch with LED indicator
3 Display
4 Softkeys
5 Measurement operation menu (to control the initiation of the measurements)
6 Measurement configuration menu (to set parameters for measurements)
7 Knob
8 Cursor navigation keypad
Label Description
1 Slot identifier (100, 200, 300)
2 External trigger input, alarm outputs, channel advance input, and channel close output
3 AC mains input
4 Instrument cable lock
5 LAN interface connector
6 Chassis ground screw
7 USB interface connector
