What's New 1
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 49
Changed
Commands
Discontinued
Commands
Command Differences
:CHANnel<n>:PROBe (see
page 354)
The probe attenuation factor can now be set from 0.001:1 to
10000:1.
:FUNCtion<m>[:FFT]:VTYPe
(see page 482)
With the FFTPhase operation, you can select vertical units in
DEGRees or RADians.
:FUNCtion<m>:OPERation (see
page 490)
The FFTPhase operation is added.
:FUNCtion<m>:SOURce1 (see
page 498)
Reference waveforms can now be specified as source 1.
:FUNCtion<m>:SOURce2 (see
page 500)
Reference waveforms can now be specified as source 2.
:POWer:HARMonics:LINE (see
page 739)
The AUTO frequency option is added. This option automatically
determines the frequency of the Current waveform.
:SBUS<n>:LIN:STANdard (see
page 980)
The LIN13NLC option is added for selecting LIN 1.3 (no length
control).
:SBUS<n>:MODE (see
page 857)
The CXPI mode is now available with the CXPI serial decode and
triggering license.
:TIMebase:REFerence (see
page 1287)
The CUSTom option is added for placing the time reference
location at a percent of the graticule width.
Discontinued Command Current Command Equivalent Comments
:POWer:CLResponse:VIEW none Because the plot now appears
in its own dialog box and
contains both gain and phase
plots, there is no longer a need
to select one or the other.
:POWer:CLResponse:YMAXimu
m
none Specifying the plot's initial
vertical scale maximum value
is no longer necessary because
the plot now appears in its own
dialog box and is autoscaled.
:POWer:CLResponse:YMINimu
m
none Specifying the plot's initial
vertical scale minimum value is
no longer necessary because
the plot now appears in its own
dialog box and is autoscaled.
:POWer:PSRR:RMAXimum none Specifying the plot's initial
vertical scale value is no longer
necessary because the plot
now appears in its own dialog
box and is autoscaled.
