Keysight InfiniiVision 1000 X-Series Oscilloscopes User's Guide 5
In This Guide
This guide shows how to use the InfiniiVision 1000 X-Series oscilloscopes.
When unpacking and using the
oscilloscope for the first time, see:
• Chapter 1, “Getting Started,” starting on page 11
When displaying waveforms and
acquired data, see:
• “Running, Stopping, and Making Single
Acquisitions (Run Control)" on page 30
• “Horizontal Controls" on page 31
• “Vertical Controls" on page 34
• “FFT Spectral Analysis" on page 38
• “Math Waveforms" on page 42
• “Reference Waveforms" on page 44
• “Display Settings" on page 45
When setting up triggers or changing
how data is acquired, see:
• “Triggers" on page 48
• “Acquisition Control" on page 52
Making measurements and analyzing
data:
• “Cursors" on page 59
• “Measurements" on page 61
• “Mask Testing" on page 63
• “Digital Voltmeter" on page 70
• “Frequency Response Analysis" on page 71
When using the built-in waveform
generator, see:
• “Waveform Generator" on page 72
When using licensed serial bus
decode and triggering features, see:
• “Serial Bus Decode/Trigger" on page 73
When saving, recalling, or printing,
see:
• “Save/Recall (Setups, Screens, Data)" on page 79
• “Print (Screens)" on page 82
