3 Short-Range Comms & IoT Mode
3.4 HRP UWB Demodulation Measurement
Auto Scaling
Toggles this function On or Off.
Remote
Command
:DISPlay:HUWB:WINDow[1]|2|3|4|8:X[:SCALe]:COUPle 0 | 1 | OFF | ON
:DISPlay:HUWB:WINDow[1]|2|3|4|8:X[:SCALe]:COUPle?
Example
:DISP:HUWB:WIND3:X:COUP ON
do the X auto scale for the third window
:DISP:HUWB:WIND3:X:COUP?
query the X auto scale state of the third window
Couplings When this parameter is ON, pressing the front-panel Restart key activates the scale coupling function,
which automatically determines scale per division and reference values based on the measurement
results
When you set the value of either "Width" on page 534 or "Ref Value" on page 535 manually, Auto
Scaling is automatically set to OFF
Preset
ON
State Saved Yes
Range
OFF|ON
Recording
Displays the Sample Rate, Sample Points and Sample Time of the saved IQ data file.
Recording and playback of signal data files is a multi-step process that involves
controls in several menus:
–
Save, Recording (under the Save hardkey or the Save icon in the File panel)
–
Recall, Recording (under the Recall hardkey or the Recall icon in the File panel)
–
Sweep, Recording (this tab)
–
Sweep, "Playback" on page 537
–
Input/Output, "Data Source" on page 2101
NOTE
A complete tutorial for Record/Playback functionality, including how to load and
save recording files, can be found in the help for the tab "Data Source" on page
2101 under Input/Output.
This menu includes the following display-only fields:
536 Short Range Comms & IoT Mode User's &Programmer's Reference
