3
4
Installation Guide
Hold the front guard with logo in upright position
and attached it to the rear guard
9.
Secure the two guards by
fastening the clips
8.
WF2003B
Fixing the fan clip with front guard
5.
Put Rear Fan Guard on Motor
1. 3.
Tighten the rear fan guard lock Screw the fan blade. Tighten the
blade xing screw rmly
Hold the front guard with logo in upright position
and attached it to the rear guard
6.
Secure the two guards by
fastening the clips
2.
4.
To Next Page
