1. Choose to place the washing machine in a dry place without direct sunlight.
2. The washing machine should be placed on a flat, solid floor and kept at a distance of
more than 5 cm from the wall to avoid noise when coliding with the wall during
dehydration.
3. Do not place the washing machine on a sloping, uneven surface; do not place the
washing machine on an unstable stand or on the floor. When using it, remove the
bottom foam and plastic pin holder to avoid damaging washing machine.
4. The washing machine should be placed as smoothly as possible. If necessary, adjust the
supporting feet (adjustment feet) on the front of the washing machine to keep the
washing machine level.
1. The bottom cover is placed between the top of the washing machine box and the foam.
Please take it out when unpacking.
2. Place the washing machine gently on side of soft object (be careful not to touch the
case).
3. Insert bottom cover along mounting slot on base until it is seated.
4. Secure the bottom cover to the base with screws (within the accessory bag).
5. Gently lift the washing machine and stabilize it.
5 6
Model
Voltage
Rated Power
Wash/Spin Capacity
Water Pressure
Water Level Volume: High
: Low
Spin Speed
Net Weight
Gross Weight
Product Dimension
(LxWxH)
Box Dimension (LxWxH)
WM150A
220-240V ~ 50/60Hz
550W
15kg
0.03-0.85MPa
Normal: 87L
Intelligent Program: 117L
Normal/Intelligent Program: 47L
600rpm
51.5kg
58.7kg
685 x 700 x 1055mm
755 x 765 x 1115mm
• Confirming horizontal level as the picture showing.
• If you have a spirit level, set the bubble
in the spirit level.
Specifications
Installation
*Specifications are subject to change without prior notice.
Installation Notes
Install the Bottom Cover
>5 cm
Screwdriver
Bottom lid
Soft substance
To Next Page
