869
Maintenance
Fuse Name Fuse rating Circuit Protected
WASHER 15A Multifunction Switch (Wiper Low & Washer Switch)
MODULE 8 10A A/C Control Module, Driver/Passenger Door Module
CLUSTER 10A Instrument Cluster (IG1)
MULTI MEDIA 15A Audio, A/V & Navigation Head Unit, Keyboard
HEATED
STEERING
15A BCM (Steering Wheel Heated)
MODULE 1 10A Console Switch, Key Solenoid, Driver/Passenger Door Module
DR LOCK 20A Door Lock Relay, Door Unlock Relay
SMART KEY 15A Smart Key Control Module
A/BAG IND 10A Instrument Cluster (Air Bag IND. Power)
TRUNK 10A Trunk Lid Relay, Fuel Filler & Trunk Open Switch, Trunk Lid Motor, ICM Relay Box (Fuel Filler Open Relay)
SUNROOF 2 20A Sunroof Control Unit (Roller)
MEMORY 1 10A
Instrument Cluster, A/C Control Module, Data Link Connector, BCM, Wireless Charger, Driver IMS Module,
Rain Sensor, ICM Relay Box (Outside Mirror Folding/Unfolding Mirror Relay), Security Indicator, Auto Light
& Photo Sensor, Driver/Passenger Door Module, Electro Chromic Mirror
S/HEATER RR 25A Rear Seat Warmer Control Module
SUNROOF 1 20A Sunroof Control Unit (Glass)
