Your vehicle at a glance
62
ENGINE COMPARTMENT
OHG011004A
The actual engine compartment in the vehicle may differ from the illustration.
1. Engine oil dipstick .....................7-29
2. Engine oil filler cap....................7-29
3. Engine coolant reservoir ...........7-31
4. Radiator cap..............................7-32
5. Brake fluid reservoir..................7-34
6. Windshield washer fluid
reservoir.....................................7-35
7. Air cleaner.................................7-37
8.
Positive battery terminal...........7-43
9. Negative battery terminal.........7-43
10. Fuse box .................................7-61
■■
3.3L Engine
