Kia OPTIMA PHEV - Occupant Rescue Guide and Components

4. Access to the
Occupants
4.5 Occupants
Rescue Guide
When dealing with
an emergency situation, refer to the components as below.
# Do not cut the body near the airbag, high voltage cable, fuel system.
17
Supplemental Restraint Syst
em Control Module (SRSCM)
Airbag
Airbag Inflator
High voltage cable
Air-conditioning line
Seat belt pretentioner
Service Plug
12V battery
Ultra-High Strength
Steel
High Voltage Battery
Air-conditioning
component
Gasoline fuel
tank & Line
OBC (On-Board charger)
12V battery (-) connector
High voltage charge
port
OPTIMA PHEV
LHD
High voltage component
