Your vehicle at a glance
83
Engine compartment
Engine compartment
Smartstream G1.6 T-GDi HEV
Smartstream G1.6 T-GDi PHEV
* The actual engine room in the vehicle may differ from the illustration.
1. Electric Control Unit (ECU) 8-5
2. Engine coolant reservoir 8-26
3. Engine coolant reservoir cap 8-26
4. Inverter coolant reservoir 8-28
5. Brake fluid reservoir 8-31
6. Air cleaner 8-34
7. Engine oil dipstick 8-25
8. Engine oil filler cap 8-25
9. Windscreen washer fluid reservoir 8-32
10.Fuse box 8-49
