Instrument Cluster / Engine Compartment
a Tachometer
b Speedometer
c Engine coolant temperature
gauge
d Fuel gauge
e Warning and indicator lights
f LCD display
Instrument cluster [4]
Engine compartment [2]
a Engine coolant reservoir [8]
b Radiator cap [8]
c Engine oil filler cap [8]
d Engine oil dipstick [8]
e Brake fluid reservoir [8]
f Engine room fuse box [8]
g Windscreen washer fluid
reservoir [8]
h Air cleaner [8]
Note: The battery is in the
luggage room.
