3
Install two supplied strips of foam tape to the back of the amplifier bracket as shown.
Install the amplifier bracket into position by first inserting the end with the tilt switch and then the opposite
end.
Note: Scan QR Code for bracket installation video.
Slide the slotted holes in the amplifier bracket under the two nuts that were loosened earlier. Re-tighten
the nuts to 11.5Nm (100in-lb). Install the wire retainer removed earlier into the provide hole in the amplifier
bracket.
