Series Voice Coils, Woofers in Parallel
Paralleled Voice Coils, Woofers in Parallel
Dual 2 Voice Coils in Dual Subwoofer Confi guration = 2 Load
Dual 4 Voice Coils in Dual Subwoofer Confi guration = 4 Load
Dual 2 Voice Coils in Dual Subwoofer confi guration = 0.5 Load
Dual 4 Voice Coils in Dual Subwoofer confi guration = 1 Load
amplifi er
+
amplifi er +
amplifi er -
amplifi er -
WARNING: If you are using multiple subwoofers that are wired in series to one another, each subwoofer must be in a separate chamber. If not, the
subwoofers could become damaged, resulting in loss of warranty.
