Kicker Comp Subwoofers
Recommended Applications / Version 2.0
Page 25
POWER HANDLING:
150W with 25HZ Subsonic Filter
set at 24db/Octave.
Without subsonic filter 75W
1.75 cf, Fb=40Hz
.30 cf = Port Vol.
C12-BOX-VENTED-175
Side View
B
F
D
28
16
2
A
12-1/4
3/4
R3/8
2
3/4
12-1/2
Cut List: 3/4" MDF
(2) 12 1/4" x 14" Top & Bottom(A)
(2) 12 1/4" x 26 1/2" Sides(B)
(2) 12 1/2" x 26 1/2" Front & Back(C)
(1) 12 1/2" x 15 1/4" Port(D)
(4) 2" x 2" Gusset(E)
Side View
12
C
7
7
āˆ…
-10-7/8
