Kicker Comp Subwoofers
Recommended Applications / Version 2.0
Page 28
POWER HANDLING:
250W with 25HZ Subsonic Filter
set at 24db/Octave.
Without subsonic filter 250W
3.00 cf, Fb=42Hz
.51 cf = Port Vol.
C15-BOX-VENTED-300
Side View
Cut List: 3/4" MDF
(2) 17" x 17" Top & Bottom(A)
(2) 17" x 28" Sides(B)
(2) 15 1/2" x 28" Front & Back(C)
(1) 15 1/2" x 16 1/4" Port(D)
(4) 2" x 2" Gusset(E)
Side View
8-1/2
2-3/4
āˆ…
-13-11/16
B
D
E
8-1/2
C
3/4
A
R3/8
2-3/4
3/4
15-1/2
17
17
29-1/2
17
