4
Step 1
Steps 2–6
Step 7
tweeter
tweeter post
coaxial mounting adapter
tweeter lead
wires
QSS crossover
0 dB
+3 dB
INPUT jumper.
Install only for 2-way confi gurations;
do not install if bi-amping.
tweeter output-level jumpers.
One of these jumpers MUST be installed. Higher
numbers mean more volume from the tweeter.
Fig. 2
Fig. 1
Confi guring the QSS for
Coaxial Operation
2014 QSS Multilingual Rev C.indd 42014 QSS Multilingual Rev C.indd 4 9/24/2013 2:31:58 PM9/24/2013 2:31:58 PM
