Kicker SS Series Technical Manual

6dB & 12dB / octave Bandpass Filters
Frequency
Response
Speaker Impedance
2 Ohms 4 Ohms 8 Ohms
L C L C L C
80-200 1.6mH 1000uF 4.7mH 500uF 9.1mH 250uF
80-400 .8mH 1000uF 1.6mH 500uF 3.3mH 250uF
100-250 1.2mH 500uF 2.4mH 270uF 4.7mH 150uF
100-400 .8mH 500uF 1.6mH 270uF 3.3mH 150uF
Frequency
Response
Speaker Impedance
2 Ohms 4 Ohms 8 Ohms
L1 C1 L2 C2 L1 C1 L2 C2 L1 C1 L2 C2
80-200
2.3mH 300uF 5.6mH 700uF 4.7mH 150uF 11mH 330uF 9.1mH 75uF 22mH 180uF
100-250 1.7mH 220uF 4.5mH 500uF 3.6mH 100uF 9.1mH 270uF 6.8mH 50uF 18mH 150uF
100-400 1.1mH 140uF 4.5mH 500uF 2.2mH 68uF 9.1mH 270uF 4.7mH 33uF 18mH 150uF
6 dB / Octave Bandpass
12 dB / Octave Bandpass
80-400
1.1mH 140uF 5.6mH 700uF 2.2mH 68uF 11mH 330uF 4.7mH 33uF 22mH 180uF
L2
C2
L1
C1
12 dB / Octave Bandpass
Kicker SSMB Series Midbass Drivers
Recommended Applications / Version 2.0
Page 11
If you are using two woofers wired in series use the table for 8 Ohm, likewise, if you
are using two woofers wired in parallel use the table for 2 ohm.
LC
6 dB / Octave Bandpass
