Kicker SSMB8 - Page 15

Wiring using an x2i Crossover
Kicker SSMB Series Midbass Drivers
Recommended Applications / Version 2.0
Page 15
Tweeter
Midrange
+
_
+
_
+
_
+
_
Crossover
Other Channel
SSMB Midbass
Components 250Hz -Up
SSMB6 / SSMB8 60Hz-250Hz
Other Channel
Rear or
Sub Out
From Source
Front Out
From Source
2-Way
Electronic Crossover
+
_
Subwoofer Up to 80Hz
Other Channel
Set Crossover switch to OFF Position
Set Crossover switch to HI PASS Position
Set Crossover switch to LO PASS Position
R
