KIDSMILL UP! - Page 6

INSTALLATION
Step 3: Slide the seat(15) and the footrest(14) into
the grooves at the desired height. To mount the
safety bar between the legs, pull the legs outwardly.
Step 4: Place the seat(15) with the curved
corners against the legs.
Step 5: Screw(6) the extender wheels(7) under the rear legs
and the glider boots(8) at the bottom of the front legs. Not
too tight!
Step 6: Place the chair on a at surface and
tighten all screws in the correct order.
6
1
2
3
4
6
7
11
10
5
9
6. (8x) 7. (2x) 8. (2x)
5
4
3
