Kinco FV100 Series User Manual

Chapter 7 List of Parameters
62
Function
code
Name
Descriptions
Unit
Factory setting
Modif.
Setting
range
1:symmetrical about origin
2:absolute value
LED unit’s place:
Characteristic choice of curve 2
0:set 0 Hz when frequency < 0 Hz
1:symmetrical about origin
2:absolute value
LED hundred’s place:
Characteristic choice of curve 3
0:set 0 Hz when frequency < 0 Hz
1:symmetrical about origin
2:absolute value
LED thousand’s place:
Characteristic choice of curve 4
0:set 0 Hz when frequency < 0 Hz
1:symmetrical about origin
2:absolute value
Group A4.Acc/Dec parameters
A4.00
Acc/Dec mode
0:Linear Acc/Dec1:S curve
1
0
X
0~1
A4.01
Acc time 2
0.0~6000.0
0.1s
20.0s
O
0~60000
A4.02
Dec time 2
0.0~6000.0
0.1s
20.0s
O
0~60000
A4.03
Acc time 3
0.0~6000.0
0.1s
20.0s
O
0~60000
A4.04
Dec time 3
0.0~6000.0
0.1s
20.0s
O
0~60000
A4.05
Acc time 4
0.0~6000.0
0.1s
20.0s
O
0~60000
A4.06
Dec time 4
0.0~6000.0
0.1s
20.0s
O
0~60000
A4.07
S curve
acceleration
starting time
10.0%~50.0%(Acc time)
A4.07+ A4.08≤90%
0.1%
20.0%
O
100~500
A4.08
S curve
acceleration
ending time
10.0%~80.0%(Acc time)
A4.07+ A4.08≤90%
0.1%
20.0%
O
100~800
A4.09
S curve
deceleration
starting time
10.0%~50.0%(Dec time)
A4.09+ A4.10≤90%
0.1%
20.0%
O
100~500
A4.10
Scurvedecelerati
on ending time
10.0%~70.0%(Dec time)
A4.09+ A4.10≤90%
0.1%
20.0%
O
100~700
A4.11~
A4.21
Reserved
-
1
0
O
0~65535
A4.22
A4.22Switch
0.00~300.00Hz 【000.00】
0.01
0.00Hz
X
0~30000
