Kinco FV20 Series User Manual

95
95
Function
code
Name
Descriptions
Unit
Factory
setting
Modif.
Setting
range
C1.25
Preset close-loop
reference 7
-10.00V ~10.00V
0.01V
0.00V
○
0~2000
C1.26
Preset close-loop
reference 8
-10.00V ~10.00V
0.01V
0.00V
○
0~2000
C1.27
Preset close-loop
reference 9
-10.00V ~10.00V
0.01V
0.00V
○
0~2000
C1.28
Preset close-loop
reference 10
-10.00V ~10.00V
0.01V
0.00V
○
0~2000
C1.29
Preset close-loop
reference 11
-10.00V ~10.00V
0.01V
0.00V
○
0~2000
C1.30
Preset close-loop
reference 12
-10.00V ~10.00V
0.01V
0.00V
○
0~2000
C1.31
Preset close-loop
reference 13
-10.00V ~10.00V
0.01V
0.00V
○
0~2000
C1.32
Preset close-loop
reference 14
-10.00V ~10.00V
0.01V
0.00V
○
0~2000
C1.33
Preset close-loop
reference 15
-10.00V ~10.00V
0.01V
0.00V
○
0~2000
C1.34
Close-loop output
reversal selection
0：The close-loop output is
negative, the drive will operate at
zero frequency.
1：The close-loop output is
negative, and the drive operate
reverse.
1
0
○
0~1
C1.35
Sleep function
selection
0：Disable
1：Enable.
1
0
○
0~1
C1.36
Sleep level
0.0～100.0%
0.1%
50.0%
○
0～1000
C1.37
Sleep latency
0.0～600.0s
0.1s
30.0s
○
0～
60000
C1.38
Wake-up level
0.0～100.0%
0.1%
50.0%
○
0～1000
C2：Simple PLC
C2.00
Simple PLC
operation mode
selector
Unit’s place of LED：
PLC operation mode
0： No function
1： Stop after single cycle
2： Keep final states after single
cycle
3： Continuous cycle
Ten’s place of LED：Start mode
0： Start from first step
1： Start from the step before
Stop (or alarm).
2： Start from the step and
frequency before stop(or alarm)
Hundred’s place of LED：
Storage after power off
0： Disable
1：Save the segment frequency
when power off
Thousand’s place of LED：
Time unit selector for each step
1
0000
×
0~1123H
