Notice:
Relay
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
BIN
1
1
1
1
0
0
0
0
1
1
1
1
0
0
0
0
1
1
1
1
0
0
0
0
1
1
1
1
0
0
0
0
DEC
240
240
240
240
D3
D2
D1
D0
For example:
D3,D2,D1,D0 is 240,240,240,240 , it means
relay32 to 29 is ON, relay 28 to 25 is OFF;
relay24 to 21 is ON, relay 20 to 17 is OFF;
relay16 to 13 is ON, relay 12 to 9 is OFF;
relay 8 to 5 is ON, relay 4 to 1 is OFF;
1 means ON; 0 means OFF
4、RS232/Ethernet Communication Protocol of Read DI,AI,Temperature,Power Meter
1
Get Digital Input
State
Send
AD-GET-INPUT-1-D1 （D1 is the number of input）
EXP：AD-GET-INPUT-1-05 get state of number 5
back
AD-GET-INPUT-1-D1-1/0 (1--Yes，0--None）
AD-GET-INPUT-1-05-1 number 5 has input signal
2
Get All Digital input
States
Send
AD-GET-INPUT-ALL
back
AD-GET-INPUT-ALL-X1-X0
X1–number 16 to 9; X0—number 8 to 1
3
Get ADC State
Send
AD-GET-ADC-1-D1
EXP：AD-GET-ADC-1-05 get state of number 5
back
AD-GET-ADC-1-D1-V (V is the voltage value)
AD-GET-ADC-1-05-4.02 （Voltage value is 4.02V）
4
Get All
ADC States
Send
AD-GET- ADC -ALL
back
AD-GET- ADC-ALL-V1-V2-……-V16
(V1-V16 is the input value)
5
Get temperature
state
Send
AD-GET-TEMP-1-D1
EXP：AD-GET-TEMP-1-05 Get the temp of number 5
back
AD-GET-TEMP-1-D1-T
T is the value of temperature.
AD-GET-TEMP-1-05-28.5
（the temperature is 28.5℃）
6
Get All temperature
states
Send
AD-GET-TEMP-ALL
EXP：AD-GET-TEMP-ALL
back
AD-GET-TEMP-ALL-T1-T2-T3-T4-T5
(T1~T5 is the value of 5 temperatures)
AD-GET-TEMP-ALL-28.38-28.31-28.25-28.31-28.06
7
Set Power meters
numbers
Send
AD-SET-KWH-NUM-N (N is the number)
EXP：AD-SET-KWH-NUM-02 (the number of meters is 2)
Before using , the number of meters should be set
first.
back
AD-SET-KWH-NUM-OK
AD-SET-KWH-NUM-OK
8
Get Power meter
state
Send
AD-GET-KWH-1-D1 （D1 is the number）
EXP：AD-GET-KWH -1-05 Get number 5 value
back
AD-GET- KWH -1-D1-K
AD-GET-KWH -1-05-100.00
（The electricity consumption is 100KWh.）
9
Get All Power meters
states
Send
AD-GET-KWH-ALL
EXP：AD-GET-KWH-ALL
back
AD-GET-KWH-ALL-ID1-K1
...........
AD-GET-KWH-ALL-IDn-Kn （n is the number）
AD-GET-KWH-ALL-1-2.444 Number 1 meter
AD-GET-KWH-ALL-2-6.357 Number 2 meter
