Connecting the RO-unit:
Connect the feed water with a ¾” flexible water connection tube to the micro filter and
the water inlet of the RO-unit (connection point 1).
Mount a ¾” flexible water connection tube to the outlet connection point of the RO-
unit (connection point 2) and connect the other end to the user application.
The connections must be made with a corrosion-resistant tube or pipe made of
stainless steel, plastic or pressure-proof rubber material to food-safe stand-
ards, for example. Fully demineralised water can cause other materials to de-
compose.
The user application must have a minimum water usages of 1 l/m.
Mount the supplied 10 mm. plastic tube at the drain connection (connection point 3).
The drain tube is correctly connected when it cannot be pulled out without ac-
tuating the lock ring.
Connect the opposite end of the drain tube to an open floor drain.
Ensure that the drain tube is without kinks and not blocked in any way as this
will ruin the membranes.
Use a ½” tube to connect the overflow at the back of the unit to an open floor drain.
Cannot be connected to the drain tube with a Tee.
This is a system safety, and the connection should be made to as a part of a proper
installation. If an error occurs at the level control of the RO-unit, excess permeate will
be led to drain.
