KING Edge - Page 4

KING LIVING CUSTOMER CARE: kingliving.com/support
40mm
(1.5")
540mm
(21.25")
540mm
(21.25")
540mm
(21.25")
68mm
(2.75")
68mm
(2.75")
1824mm
(71.75")
1824mm
(71.75")
5
9
8
7
2 4
1512mm
(59.5")
Assembly Top Unit
SHELF SHOULD BE FIT ON BACK PANEL
WITH “T-BAR” / FIXED BY SCREWS
TO FIT BACK PANEL / SHELF
ONTO HANGING RAIL
TO FIX RAIL FOR HANGING BOX
PUSH
PUSH
4
