Kingfisher DDD500WT151DA - Installation

24
Installation
IMPORTANT : Please follow the safety advice set out on pages 3 to 5.
[06]x04
[04]x04
[10]x04
[07]x04
[09]x04
[01]
[06]
[10]
[09]
[07]
[04]
Min. 150 mm
from the ceiling
Min. 600 mm
from the oor
The screws and wall plugs supplied are suitable for solid walls.
For all other types of wall, please use suitable screws and wall plugs.
