FPCSP41-3
Your product
Getting started...
20
Your product
1. Rear handle
2. Throttle interlock
3. Throttle trigger
4. Primer
5. Choke lever
6. Fixing screw
a. Air lter cover
b. Air lter*
c. Rubber sealing*
7. Spark plug
connector*
a. Spark plug*
8. Front handle
9. Front hand guard
(chain brake lever)
10. Saw chain
11. Guide bar
a. Lubrication hole
b. Sprocket wheel
c. Tension hole*
12. Retaining nut (x2)
13. Tension screw
a. Tension pin*
14. Cover
15. Cylinder ns
a. Mufer
16. Oiling port
17. Bolt (x2)
18. Spiked bumper
a. Protective cap
19. Chain catch
20. Clutch
21. Drive sprocket*
22. Chain oil ow
adjustment screw*
23. Ignition switch (on/
off)
24. Chain oil tank cap
25. Fuel tank cap
26. Engine speed
adjustment screw
27. Recoil starter handle
28. Air vents
29. Guide bar cover
30. Fuel mixing bottle
31. Multi-tool
32. Screwdriver
NOTE: Parts marked with * are not shown in this overview. Please
refer to the respective section in the instruction manual.
